Ubiquiti UniFi Switch fully managed, PoE+ Gigabit switches

The Ubiquiti UniFi Switch is a range of fully managed, PoE+ Gigabit switches that deliver robust performance and intelligent switching for scalable networks. It also offers additional fibre uplink connectivity options.

Ubiquiti UniFi Switch is available with 8, 16, 24, or 48 PoE Gigabit Ethernet ports of auto- sensing IEEE 802.3af/at, or configurable 24V Passive PoE using the UniFi Controller software

Ubiquiti UniFi Switch Flex 5-Port Layer 2 Gigabit with PoE Support (USW-FLEX)

The Ubiquiti UniFi Switch USW-FLEX is a configurable Layer 2 Gigabit switch with auto-sensing 802.3af PoE. It offers five RJ45 Gigabit Ethernet ports, providing 1 PoE input and 4 PoE output links to your devices.


Ubiquiti UniFi Switch USW-FLEX Key Features

  • Auto-sensing 802.3af PoE
  • 5 RJ45 Gigabit Ethernet ports
  • Switching Performance
  • PoE Flexibility
  • Indoor/Outdoor Design
  • Versitile Mounting
  • Seamless Integration


Versatile Mounting

The USW-Flex can be installed horizontally or vertically making it ideal for desktop, magnetic wall-mount, and pole-mount installations.

Versatile Mounting

Indoor/Outdoor Design
The USW-Flex is designed for indoor or outdoor use. With its weatherproof housing and versatile mounting options, the USW-Flex provides both flexibility and durability for environments with extreme temperature variations.

Indoor/Outdoor Design

Ubiquiti UniFi Switch USW-FLEX – Technical Specifications

General

  • Dimensions: 122.5 x 107.1 x 28.0 mm (4.82 x 4.22 x 1.10″)
  • Weight: 230 g (8.11 oz)
  • Networking Interfaces: (5) 10/100/1000 Mbps RJ45 Ports
  • Management Interface: Ethernet In-Band
  • Power Method (Port 1):
    – PoE Mode 1: 802.3af/at (Pins 1, 2+; 3, 6-)1
    – PoE Mode 2: 802.3bt (Pins 1, 2+; 3, 6- and 4, 5+; 7, 8-)2
    – PoE Mode 3: 50V/60W PoE Adapter3
  • PoE Out (Ports 2-5): 802.3af (Pins 1, 2+; 3, 6-)
  • Max. Power Consumption (Excluding PoE Output): 5W
  • Max PoE Wattage Per Port: 15.4W
  • Total PoE Power Budget:
    – Powered by AF mode PSE: 8W
    – Powered by AT mode PSE: 20W
    – Powered by BT mode PSE: 46W
    – Powered by PoE Adapter (Enabled in Controller): 46W
  • Voltage Range:
    – 802.3af: 44 – 57V
    – 802.3at/bt: 50 – 57V
  • LEDs:
    – System: Status
    – RJ45 Data Ports: PoE; Link/Speed/Activity
  • ESD/EMP Protection: ± 16kV Air, ± 16kV Contact
  • Operating Temperature:
    – 46W PoE Output: -40 to 55° C (-40 to 131° F)
    – 25W PoE Output: -40 to 65° C (-40 to 149° F)
  • Operating Humidity: 5 to 95% Noncondensing
  • Certifications: CE, FCC, IC

1 Recommended PoE power source: US-8-150W (sold separately)
2 Recommended PoE power source: USW-Industrial (sold separately)
3 Recommended PoE power source: POE-50-60W-WH (sold separately)
(POE-50-60W-WH requires enabling injector mode in UniFi Controller)

Ubiquiti UniFi USW Flex Mini 5-Port Layer 2 Gigabit Switch – EU Power Supply (USW-Flex-Mini)

The Ubiquiti UniFi USW-Flex-Mini is a smart managed Gigabit switch. It offers 5 RJ45 Ethernet ports, providing 1 Gigabit links to your devices. Power up the USW-Flex-Mini with the included USB Type-C (european only) power adapter or with 802.3af PoE Ethernet in port 1.

Ubiquiti UniFi USW-Flex-Mini Key Features

  • Powered by 802.3af/at PoE or USB Type C (european only)
  • Compact Desktop Footprint
  • Energy-Efficient Design
  • 5x 10/100/1000 RJ45 ports
  • 1x 802.3af/at PoE input port

Compact Desktop Design
The cost-effective UniFi Switch Flex Mini can be discreetly integrated into any environment.

Copper Connectivity
Five RJ45 ports offer 10/100/1000 links. One port also supports 802.3af/at PoE input.

Efficient Use of Energy
The UniFi Switch Flex Mini uses only a maximum of 2.5W. For your convenience, it can be powered by 802.3af/at PoE or a 5V, 1A USB-C power adapter (european only)

Switching Performance
The UniFi Switch Flex Mini offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.Ubiquiti UniFi USW-Flex-Mini – Technical Specifications

General

  • Dimensions: 107.16 x 70.15 x 21.17 mm (4.22 x 2.76 x 0.83″)
  • Weight: 150 g (5.29 oz)
  • Interfaces:
    – Networking: (5) 10/100/1000 RJ45 Ports
    – PoE In: 802.3af/at PoE (Pins 1, 2+; 3, 6-)
    – Management: Ethernet In-Band
  • Total Non-Blocking Throughput: 5 Gbps
  • Switching Capacity: 10 Gbps
  • Forwarding Rate: 7.44 Mpps
  • Power Method:
    – USB Type C, 5V
    – 802.3af/at PoE (44 – 57VDC, 0.05 – 0.04A)
  • Voltage Range:
    – USB Type C: 4.7 – 5.3V
    – 802.3af/at PoE: 44 – 57VDC
  • Max Power Consumption: 2.5W
  • LEDs:
    – System: Status
    – RJ45 Data Ports: Speed/Link/Activity
  • ESD/EMP Protection: Air: ±16 kV, Contact: ±12 kV
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature: -5 to 45° C (23 to 113° F)
  • Operating Humidity: 10 – 90% Noncondensing
  • Certifications: CE, FCC, IC

Ubiquiti UniFi Switch 8 Port – US-8 (Non-PoE)

The Ubiquiti UniFi US-8 is a non-PoE 8 port gigabit switch, which supports PoE passthrough. It is perfect for cleanly adding Ethernet ports where needed, all in a compact form factor. Alike the other UniFi Switches, the US-8 is fully manageable, delivering robust performance for your network.

Ubiquiti UniFi US-8 Key Features

  • 5x US-8
  • (8) Gigabit RJ45 Ports
  • (1) PoE Passthrough Port
  • Non-Blocking Throughput: 8 Gbps
  • Switching Capacity: 16 Gbps
  • Forwarding Rate: 11.9 Mpps
  • Maximum Power Consumption: 12W
  • PoE or DC Input Option

8-Port Managed Gigabit Switches
The US-8-60W is an 8-port gigabit switch with four 802.3af PoE ports. Its auto-sensing PoE ports deliver up to 15.4W of power per port.
The US-8 is a PoE Powered 8-port gigabit switch with PoE Passthrough. Perfect for cleanly adding Ethernet ports where needed, with passthrough to keep your PoE device powered.
8-Port Managed Gigabit Switches

Non-Blocking Throughput
The new 8-port models feature Gigabit Ethernet ports in a compact form factor. For its total, non-blocking throughput, each UniFi Switch supports up to 8 Gbps.
Non-Blocking Throughout

Switching Capacity
The UniFi Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss, with a switching capacity of 16 Gbps.
Switching Capacity

Seamless Integration
A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralised interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.
Seamless Integration

Ubiquiti UniFi US-8 – Technical Specifications

General

  • Dimensions: 148.0 x 99.5 x 30.7 mm (5.83 x 3.92 x 1.21″)
  • Weight: 432 g (15.24 oz)
  • Enclosure Characteristics: SGCC Steel
  • Total Non-Blocking Throughput: 8 Gbps
  • Switching Capacity: 16 Gbps
  • Forwarding Rate: 11.9 Mpps
  • Max. Power Consumption: 12W (Excluding PoE Output)
  • Max. Passive PoE Wattage per Port:
    – PoE Mode 1: 12W @ 802.3at
    – PoE Mode 2: 12W @ 48V
    – DC Input Mode: 12W @ 48V
  • Passive PoE Voltage Range: Depends on Power Source
  • Power Method:
    – (1) DC 48V, Max. 1.25A
    – (1) PoE Input, 802.3 af/at (Pins +1, 2; -3, 6)
  • Supported Voltage Range: DC: 48V; 48V Mode: 56V to 40V
  • Power Supply: External AC/DC Adapter, 48V, 0.5A
  • LEDs: PoE (Port 8), Speed/Link/Activity (All Ports)
  • Sound Level (Background noise level: 27.5 dBa): 0.7 dBr (Fanless)
  • Networking Interfaces: (8) 10/100/1000 Mbps RJ45 Ports
  • PoE In Interface (Port 1):
    – PoE Mode 1: 802.3af/at (Pins +1, 2; -3, 6)
    – PoE Mode 2: 48V (Pins +4, 5; -7, 8)
  • PoE Out Interface (Port 8):
    – PoE Mode 1: 48V (Pins +1, 2; -3, 6)
    – PoE Mode 2: Passive 48V (Pins +4, 5; -7, 8)
    – DC Input Mode: DC Passthrough (Pins +1, 2; -3, 6)
  • Management Interface: Ethernet In-Band Management
  • ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV
  • Operating Temperature: -5 to 45° C (23 to 113° F)
  • Operating Humidity: 5 to 95% Noncondensing
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Certifications: CE, FCC, IC

Ubiquiti UniFi Switch Lite 8-Port PoE Switch (USW-Lite-8-POE-EU)

The Ubiquiti UniFi Switch Lite 8 PoE is a fully managed Layer 2 switch with eight Gigabit Ethernet ports for your RJ45 Ethernet devices. Four ports also offer auto-sensing 802.3at PoE+ that provide up to a total of 52W PoE wattage for UniFi Access Points or other PoE devices.

Ubiquiti UniFi USW-Lite-16-PoE-EU Switch key features

  • Eight Gigabit RJ45 ports including four 802.3at PoE+ ports
  • Managed by UniFi Controller (5.13.10 or later)
  • External 60W power adapter
  • Wall-mountable (Kit included)

The USW-Lite-8-PoE is managed and configured by the UniFi Network Controller with UniFi mobile app support and offers Layer 2 switching protocols and features. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere Ubiquiti UniFi USW-Lite-8-PoE-EU Technical Specification

Product Specifications

  • Dimensions: 99.6 x 163.7 x 31.7 mm (3.92 x 6.44 x 1.25″)
  • Weight: 450g (15.87 oz)
  • Total Non-Blocking Line Rate: 8 Gbps
  • Max. Power Consumption: 8W
  • Power Method: 54VDC, 1.1A Power Adapter
  • Power Supply: External 54V/60W Power Adapter
  • Supported Voltage Range: DC 50V to 57V
  • Networking Interfaces: (8) 10/100/1000 Mbps Ethernet RJ45 ports
  • PoE Interfaces:(4) PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
  • Mangement Interface Ethernet In-Band
  • Max PoE+ Wattage per Port by PSE: 30W
  • Modes: SMB Layer 2 PoE Gigabit Ethernet Switch
  • Operating Temperature: -15 to 40° C (5 to 104° F)
  • Operating Humidity: 10 – 90% Noncondensing
  • Certifications: CE, FCC, IC

LED

  • System
    – (1) Power, Blue/WhiteFlashing White: Bootup in Progress
    – Flashing Blue: Firmware Upgrading
    – Steady White: Factory Defaults, Awaiting Adoption
    – Steady Blue: Device is Adopted
  • Ethernet Green: 1G, Amber: 10/100 Mbps
  • PoE Amber: IEEE 802.3af/at

Ubiquiti UniFi Switch 8 Port – US-8-60W – 5 Pack

The Ubiquiti UniFi US-8-60W is an 8-port gigabit switch with four 802.3af PoE ports. The US-8-60W auto-sensing PoE ports deliver up to 15.4W of power per port all in a compact form factor. Alike the other UniFi Switches, the US-8-60W is fully manageable, delivering robust performance for your network.

Ubiquiti US-8 5 Pack Key Features

  • Five units of US-8-60W included
  • (8) Gigabit RJ45 Ports per Switch
  • (4) Auto-Sensing IEEE 802.3af PoE Ports per Switch
  • Non-Blocking Throughput: 8 Gbps
  • Switching Capacity: 16 Gbps
  • Forwarding Rate: 11.9 Mpps
  • Maximum Power Consumption: 12W
  • Power Supply Included

Ubiquiti US-8-60W 5 Pack Technical Specification

General

  • Dimensions
    148.0 x 99.5 x 30.7 mm (5.83 x 3.92 x 1.21″)
  • Weight
    432 g (15.24 oz)
  • Enclosure Characteristics
    SGCC Steel
  • Total Non-Blocking Throughput
    8 Gbps
  • Switching Capacity
    16 Gbps
  • Forwarding Rate
    11.9 Mpps
  • Max. Power Consumption
    12W (Excluding PoE Output)
  • Max. PoE Wattage per Port
    15.4W
  • Power Method
    48VDC, Max. 2A
  • Supported Voltage Range
    57VDC to 44VDC
  • Power Supply
    External AC/DC Adapter, 48V, 1.25A
  • LEDs
    PoE (Port 8), Speed/Link/Activity (All Ports)
  • Networking Interfaces
    (8) 10/100/1000 Mbps RJ45 Ports
  • PoE Interfaces
    (4) Ports 5, 6, 7, 8; IEEE802.3af
  • ESD/EMP Protection
    Air: ± 24 kV, Contact: ± 24 kV
  • Operating Temperature
    -5 to 45° C (23 to 113° F)
  • Operating Humidity
    5 to 95% Noncondensing
  • Shock and Vibration
    ETSI300-019-1.4 Standard
  • Certifications
    CE, FCC, ICDatasheet

Ubiquiti UniFi US-8-150W Switch

The Ubiquiti UniFi US-8-150W is a fully managed 8 port PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks. The US-8-150W is a fanless UniFi switch which delivers a quiet yet powerful performance.

Ubiquiti UniFi Switch 8 150W Key Features

  • (8) Gigabit RJ45 Ports
  • (2) SFP Ports
  • Non-Blocking Throughput: 10 Gbps
  • Switching Capacity: 20 Gbps
  • Forwarding Rate: 14.88 Mpps
  • Maximum Power Consumption: 150W
  • Supports PoE+ IEEE 802.3at/af and 24V Passive PoE
  • Quiet, Fanless Operation
  • Desktop-Mountable (Do not physically stack the US-8-150W.)

Versatile Port Configuration
Eight Gigabit RJ45 ports offer different power output options: auto-sensing IEEE 802.3af/at PoE/PoE+ and 24V passive PoE, and two SFP ports provide optical fiber connectivity options to support uplinks of up to 1 Gbps.
Versatile Port Configuration

Wall Mounting
Mounting Accessories support any orientation wall-mount and desk/shelf mounting.
Wall Mounting

Sleek Design and Management
The compact UniFi Switch can be placed on a desktop and integrates with the UniFi Controller software for centralized management of your UniFi devices.
Sleek design and management

Advanced Enterprise Switching
The UniFi Switch supports 802.1X authentication, dynamic and static VLAN tagging, port isolation, storm control, and guest control.

Advanced Enterprise Switching

Ubiquiti UniFi Switch 8 150W – Technical Specifications

General

  • Dimensions: 235 x 43 x 204 mm (9.25 x 1.69 x 8.03″)
  • Weight: 1.65 kg (3.67 lb)
  • Networking Interfaces:
    – (8) 10/100/1000 Mbps RJ45 Ethernet Ports
    – (2) 1 Gbps SFP Ethernet Ports
  • Management Interface: Ethernet In-Band
  • Total Non-Blocking Throughput: 10 Gbps
  • Switching Capacity: 20 Gbps
  • Forwarding Rate: 14.88 Mpps
  • MAC Address Table: 16384
  • Maximum Aggregations: 6
  • Monitoring Sessions: 1
  • Maximum VLANs: 255
  • Power Method: 100-240VAC/50-60 Hz, Universal Input
  • Power Supply: AC/DC, Internal, 150W DC
  • Max. Power Consumption:
    – Including PoE Output: 150W
    – Excluding PoE Output: 20W
  • LEDs Per Port:
    – RJ45 Data Ports: PoE, Speed/Link/Activity
    – SFP Data Ports: Speed/Link/Activity
  • Sound Level (Background noise level: 27.5 dBa): 0.5 dBr (Fanless)
  • ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature -5 to 40° C (23 to 104° F)
  • Operating Humidity 5 to 95% Noncondensing
  • Certifications CE, FCC, IC

PoE+ Per Port

  • PoE Interfaces:
    – PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
    – 24VDC Passive PoE (Pins 4, 5+; 7, 😎
  • Max. PoE+ Wattage per Port by PSE: 34.2W
  • Voltage Range 802.3at Mode: 50–57V
  • Max. Passive PoE Wattage per Port: 17W
  • 24V Passive PoE Voltage Range: 20-27V

Ubiquiti UniFi 16-Port PoE Switch (USW-16-POE)

The Ubiquiti UniFi USW-16-PoE Switch is a configurable Gigabit Layer 2 switch with 16 Gigabit Ethernet ports including eight auto-sensing 802.3at PoE+ ports, and two SFP ports.

Ubiquiti UniFi USW-16-POE Switch key features

  • 16x 10/100/1000 RJ45 Ports
  • 8x auto-sensing 802.3at PoE+ ports
  • 2x SFP ports
  • 1.3” touch LCM to provide status information
  • Compact, fanless design

The USW-16-POE provides Gigabit PoE links to RJ45 Ethernet devices and Gigabit fiber uplink options to enterprise networks. The switch features a 1.3″ touch LCM to provide status information. With a depth of 7.9″, the compact fanless design can be easily installed in a SOHO rack cabinet.

Managed and configured by the UniFi Network Controller with UniFi mobile app support, the USW-16-POE offers an extensive suite of advanced Layer 2 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.

Near silent cooling

Ubiquiti’s new airflow design reduces the need for fan usage.

New airflow design reduces need for fan usage

Powerful hardware and software

Ubiquiti UniFi Gen2 Switches offer a variety of features, including 10G SFP+ ports, PoE+ or PoE++ support, and Layer 3* switching capabilities. (*Layer 3 switching will be available in a future software release)

Powerful hardware and software

UniFi SmartPower RPS, USP-RPS, is Ubiquiti’s PSU failover system.

In the event of a UniFi switch power supply failure, the USP-RPS automatically supplies redundant power to the failed device. One UniFi SmartPower device can support up to 6 devices until the failed device is replaced.

UniFi SmartPower

Touch screen display

The 1.3″ touchscreen display allows easy monitoring and quick troubleshooting


Synchronised LCM touch screen displays Ubiquiti UniFi USW-16-POE Switch Technical Specification

Product Specifications

  • Dimensions: 442.4 x 200 x 43.7 mm (17.42 x 7.87 x 1.72″)
  • Weight: 2.80 kg (6.17 lb)
  • Weight with Brackets: 2.89 kg (6.37 lb)
  • Interfaces:
    – Networking: (16) 10/100/1000 RJ45 Ports, (2) 1G SFP Ethernet Ports
    – Management: Ethernet In-Band
  • Total Non-Blocking Throughput: 18 Gbps
  • Switching Capacity: 36 Gbps
  • Forwarding Rate: 26.78 Mpps
  • Power Method: 100-240VAC, 50/60 Hz, Universal Input
  • Power Supply: AC/DC, Internal, 60W
  • Voltage Range: 100 to 240VAC
  • Max Power Consumption (Excluding PoE Output): 18W
  • LEDs:
    – System: Status
    – RJ45 Data Ports: PoE; Speed/Link/Activity
    – SFP Data Ports: Link/Activity
  • ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature: -5 to 40° C (23 to 104° F)
  • Operating Humidity: 10 – 90% Noncondensing
  • Certifications: CE, FCC, IC

PoE

  • Total Available PoE: 42W
  • PoE Interfaces:
    – Ports 1-8: POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
  • Max. PoE Wattage per Port by PSE:
    – 802.3at: 32W
  • Voltage Range:
    – 802.3af Mode: 44-57V
    – 802.3at Mode: 50-57V

Ubiquiti UniFi Switch Lite 16-Port PoE Switch (USW-Lite-16-POE-EU)

The Ubiquiti UniFi Switch Lite 16 PoE is a fully managed Layer 2 switch with sixteen Gigabit Ethernet ports for your RJ45 Ethernet devices. Eight ports also offer auto-sensing 802.3at PoE+ that provide up to a total of 45W PoE wattage for UniFi Access Points or other PoE devices.

Ubiquiti UniFi USW-Lite-16-PoE-EU Switch key features

  • 16 Gigabit RJ45 ports including eight 802.3at PoE+ ports
  • Managed by UniFi Controller
  • 60W power supply
  • Wall-mountable (Kit included)

The UniFi Switch Lite 16 PoE is managed and configured by the UniFi Network Controller with UniFi mobile app support and offers Layer 2 switching protocols and features. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere Ubiquiti UniFi USW-Lite-16-PoE-EU Technical Specification

Product Specifications

  • Dimensions: 191.7 x 185 x 43.7 mm (7.55 x 7.28 x 1.72″)
  • Weight:1.2 kg (2.65 lb)
  • Total Non-Blocking Line Rate: 16 Gbps
  • Max. Power Consumption: 15W
  • Power Method Universal AC Input: 100-240VAC
  • Power Supply: Internal 60W AC/DC Power Supply
  • Networking Interfaces: (16) 10/100/1000 Mbps Ethernet RJ45
  • PoE Interfaces: (8) PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
  • Mangement Interface Ethernet In-Band
  • Max PoE+ Wattage per Port by PSE 30W
  • Modes: SMB Layer 2 PoE Gigabit Ethernet Switch
  • Operating Temperature: -15 to 40° C (5 to 104° F)
  • Operating Humidity: 10 – 90% Noncondensing
  • Certifications: CE, FCC, IC

LED

  • System
    – (1) Power, Blue/WhiteFlashing White: Bootup in Progress
    – Flashing Blue: Firmware Upgrading
    – Steady White: Factory Defaults, Awaiting Adoption
    – Steady Blue: Device is Adopted
  • Ethernet Green: 1G, Amber: 10/100 Mbps
  • PoE Amber: IEEE 802.3af/at

Ubiquiti UniFi US-16-150W Switch

The  Ubiquiti UniFi US-16-150W delivers robust performance over its 18 independent switching ports. Two SFP ports offer optical connectivity, and 16 Gigabit Ethernet ports of auto-sensing IEEE 802.3af/at or configurable 24V passive PoE allow you to simplify your infrastructure.

Ubiquiti UniFi US-16-150W Key Features

  • 16 x Gigabit RJ45 Ports
  • 2 x SFP Ports
  • 1 x Serial Console Port
  • Non-Blocking Throughput: 18 Gbps
  • Switching Capacity: 36 Gbps
  • Forwarding Rate: 26.78 Mpps
  • Maximum Power Consumption: 150W
  • Supports PoE+ IEEE 802.3at/af and 24V Passive PoE
  • Rack-Mountable or Wall-Mountable with Rack-Mount Brackets (Included)

The UniFi US-16-150W delivers robust performance, intelligent switching for growing networks and provides the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.

Versatile Mounting Options
The UniFi US-16-150W can be placed either on a desktop, on a wall, or in a rack.

Mounting option for US-16-150W
Versatile Port Configuration

Sixteen Gigabit RJ45 ports offer different power output options: auto-sensing IEEE 802.3af/at PoE/PoE+ and 24V passive PoE, and two SFP ports provide optical fiber connectivity options to support uplinks of up to 1 Gbps.

Image of 16 PoE Gigabit RJ45 Ports and 2 SFP Ports
Integration with UniFi Controller
The UniFi US-16-150W integrates with the UniFi Controller software for centralised management of your UniFi devices.

Photo of how US-16-150W  UniFi Controller software works across devicesUbiquiti UniFi Switch 16 150W – Technical Specifications

General

  • Dimensions: 443 x 43 x 221 mm (17.44 x 1.69 x 8.70″)
  • Weight:
    – Rack-Mount Brackets Excluded – 2.80 kg (6.17 lb)
    – Rack-Mount Brackets Included – 2.89 kg (6.37 lb
  • Networking Interfaces:
    – 16 x 10/100/1000 Mbps RJ45 Ethernet Ports
    – 2 x 1 Gbps SFP Ethernet Ports
  • Management Interface: Ethernet In-Band
  • Total Non-Blocking Throughput: 18 Gbps
  • Switching Capacity: 36 Gbps
  • Forwarding Rate: 26.78 Mpps
  • MAC Address Table: 16384
  • Maximum Aggregations: 6
  • Monitoring Sessions: 1
  • Maximum VLANs: 255
  • Power Method: 100-240VAC/50-60 Hz, Universal Input
  • Power Supply: AC/DC, Internal, 150W DC
  • Max. Power Consumption:
    – Including PoE Output: 150W
    – Excluding PoE Output: 28W
  • LEDs Per Port:
    – RJ45 Data Ports: PoE, Speed/Link/Activity
    – SFP Data Ports: Speed/Link/Activity
  • Sound Level (Background noise level: 27.5 dBa):
    – Fan Level: 0: 1.7 dBr
    – Fan Level: 1, 2, 3: 10.8 dBr
  • ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature: -5 to 40° C (23 to 104° F)
  • Operating Humidity: 5 to 95% Noncondensing
  • Certifications: CE, FCC, IC

PoE+ Per Port

  • PoE Interfaces:
    – PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
    – 24VDC Passive PoE (Pins 4, 5+; 7, 😎
  • Max. PoE+ Wattage per Port by PSE: 34.2W
  • Voltage Range 802.3at Mode: 50–57V
  • Max. Passive PoE Wattage per Port: 17W
  • 24V Passive PoE Voltage Range: 20-27V

Ubiquiti UniFi Switch 24 US-24 (NON-POE)

The Ubiquiti UniFi US-24 (NON-POE) is a fully managed twenty-four port switch that delivers robust performance, intelligent switching for growing networks. The Ubiquiti UniFi US-24 delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.

Ubiquiti UniFi US-24 Key Features

  • (24) Gigabit RJ45 Ports
  • (2) SFP Ports
  • (1) Serial Console Port
  • Non-Blocking Throughput: 26 Gbps
  • Switching Capacity: 52 Gbps
  • Forwarding Rate: 38.69 Mpps
  • Maximum Power Consumption: 25W
  • Rack-Mountable

Powerful Enterprise Switch Models
The UniFi® Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. For its total, non‐blocking throughput, the US-24 supports up to 26 Gbps, while the 48-port model supports up to 70 Gbps.

Powerful Enterprise Switch Models

Multi-Site Management
A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralised interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.
Multi-Site Management

Optical Fiber Backhaul
Two SFP ports support uplinks of up to 1 Gbps. For high-capacity uplinks, each 48-port model includes two SFP+ ports for uplinks of up to 10 Gbps.
Optical Fiber Backhaul

Non-Blocking Throughput
For its total, non‐blocking throughput, the US-24 supports up to 26 Gbps, while the 48-port model supports up to 70 Gbps.
Non-Blocking Throughout

Switching Capacity
The UniFi US-24 offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.
Switching Capacity

Versatile Mounting Options
The UniFi Switch can be placed on a desktop or mounted on a wall or in a rack.
Versatile Mounting Options

Seamless Integration
The UniFi US-24 switch integrates seamlessly into the UniFi Software-Defined Networking (SDN) platform to create a highly scalable, end-to-end system of network devices across multiple locations — all controlled from a single interface.



Ubiquiti UniFi US-24 (NON-POE) – Technical Specifications

General

  • Dimensions: 443 x 43 x 221 mm (17.44 x 1.69 x 8.70″)
  • Weight:
    – Rack-Mount Brackets Excluded – 2.51 kg (5.53 lb)
    – Rack-Mount Brackets Included – 2.60 kg (5.70 lb)
  • Networking Interfaces:
    – (24) 10/100/1000 Mbps RJ45 Ethernet Ports
    – (2) 1 Gbps SFP Ethernet Ports
  • Management Interface: (1) RJ45 Serial Port Out-of-Band, Ethernet In-Band
  • Total Non-Blocking Throughput: 26 Gbps
  • Switching Capacity: 52 Gbps
  • Forwarding Rate: 38.69 Mpps
  • Power Method: 100-240VAC/50-60 Hz, Universal Input
  • Power Supply: AC/DC, Internal, 25W DC
  • Max. Power Consumption: 25W
  • LEDs per Port: Speed/Link/Activity
  • Sound Level (Background noise level: 27.5 dBa):
    – Fan Level: 0: 1.6 dBr
    – Fan Level: 1: 9.2 dBr
  • ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV
  • Rack Mount: Yes, 1U High
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature: -5 to 40° C (23 to 104° F)
  • Operating Humidity: 5 to 95% Noncondensing
  • Certifications: CE, FCC, IC

Ubiquiti UniFi Switch US-24-250W

The UniFi US-24-250W is a fully managed 24 port PoE+ Gigabit switch that delivers robust performance, intelligent switching for growing networks and the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.

Ubiquiti UniFi US-24-250W Key Features

  • (24) Gigabit RJ45 Ports
  • (2) SFP Ports
  • (1) Serial Console Port
  • Non-Blocking Throughput: 26 Gbps
  • Switching Capacity: 52 Gbps
  • Forwarding Rate: 38.69 Mpps
  • Maximum Power Consumption: 250W
  • Supports PoE+ IEEE 802.3at/af and 24V Passive PoE
  • Rack-Mountable

Powerful Enterprise Switch Models
The US-24-250W delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. Total non-blocking throughput: up to 26 Gbps for the US-24-250W and up to 70 Gbps for 48-port models.

Powerful Enterprise Switch

Advanced Port Management
Each switch port offers custom settings: port name, PoE, network/VLAN configuration, and operation mode (switching, mirroring, or aggregate) – as well as 802.1X Authentication and Radius VLAN support.
Advanced Port Management


Optical Fiber Connectivity
Two SFP ports support uplinks of up to 1 Gbps. For high-capacity uplinks, each 48-port model includes two SFP+ ports for uplinks of up to 10 Gbps.
Optical Fiber Connectivity


Convenient PoE+ Support
The US-24-250W features auto-sensing IEEE 802.3af/at PoE to power multiple devices on the network.
Convenient PoE+ Support


Seamless Integration
The US-24-250W integrates seamlessly into the UniFi Software-Defined Networking (SDN) platform to create a highly scalable, end-to-end system of network devices across multiple locations — all controlled from a single interface.

Seamless IntegrationUbiquiti UniFi US-24-250W – Technical Specifications

General

  • Dimensions: 485 x 43.7 x 285.4 mm (19.09 x 1.72 x 11.24″)
  • Weight: 4.7 kg (10.4 lb)
  • Networking Interfaces:
    – (24) 10/100/1000 Mbps RJ45 Ethernet Ports
    – (2) 1 Gbps SFP Ethernet Ports
  • Management Interface: (1) RJ45 Serial Port Out-of-Band, Ethernet In-Band
  • Total Non-Blocking Throughput: 26 Gbps
  • Switching Capacity: 52 Gbps
  • Forwarding Rate: 38.69 Mpps
  • MAC Address Table: 16384
  • Maximum Aggregations: 6
  • Monitoring Sessions: 1
  • Maximum VLANs: 255
  • Power Method: 100-240VAC/50-60 Hz, Universal Input
  • Power Supply: AC/DC, Internal, 250W DC
  • Max. Power Consumption:
    – Including PoE Output: 250W
    – Excluding PoE Output: 30W
  • LEDs Per Port:
    – RJ45 Data Ports: PoE, Speed/Link/Activity
    – SFP Data Ports: Speed/Link/Activity
  • Sound Level (Background noise level: 27.5 dBa):
    – Fan Level 0: 9.1 dBr
    – Fan Level 1: 14.2 dBr
    – Fan Level 2: 16.8 dBr
    – Fan Level 3: 21.2 dBr
  • ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature: -5 to 40° C (23 to 104° F)
  • Operating Humidity: 5 to 95% Noncondensing
  • Certifications: CE, FCC, IC

PoE+ Per Port

  • PoE Interfaces:
    – PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
    – 24VDC Passive PoE (Pins 4, 5+; 7, 8-
  • Max. PoE+ Wattage per Port by PSE: 34.2W
  • Voltage Range 802.3at Mode: 50–57V
  • Max. Passive PoE Wattage per Port: 17W
  • 24V Passive PoE Voltage Range: 20-27V

Ubiquiti UniFi 24 Port PoE Pro Switch (USW-Pro-24-POE)

The Ubiquiti UniFi USW Pro 24-POE is a configurable, Gigabit Layer 2 and Layer 3 switch with auto-sensing 802.3at PoE+ and 802.3bt PoE++.

Ubiquiti UniFi USW-24-POE Pro Switch key features

  • 24x 10/100/1000 RJ45 ports
  • (1-16) IEEE 802.3af/at PoE+ ports
  • (17-24) 60W IEEE 802.3bt PoE++ ports
  • 2 x 1/10G SFP+ Ethernet Ports
  • 1.3” touch LCM to provide status information
  • Compact, fanless design

16 PoE+ and eight PoE++ RJ45 ethernet ports have total 400W PoE budget, and two SFP+ ports offer 10Gbps uplink options. Near-silent cooling and a 1.3″ touch LCM.

Note: Layer3 will be included in later software release

Near silent cooling

Ubiquiti’s new airflow design reduces the need for fan usage.

New airflow design reduces need for fan usage

Powerful hardware and software

Ubiquiti UniFi Gen2 Switches offer a variety of features, including 10G SFP+ ports, PoE+ or PoE++ support, and Layer 3* switching capabilities. (*Layer 3 switching will be available in a future software release)

Powerful hardware and software

UniFi SmartPower RPS, USP-RPS, is Ubiquiti’s PSU failover system.

In the event of a UniFi switch power supply failure, the USP-RPS automatically supplies redundant power to the failed device. One UniFi SmartPower device can support up to 6 devices until the failed device is replaced.

UniFi SmartPower

Touch screen display

The 1.3″ touchscreen display allows easy monitoring and quick troubleshooting


Synchronised LCM displays Ubiquiti UniFi UniFi USW Pro 24 POE Technical Specification

Product Specifications

  • Dimensions: 442.4 x 285.4 x 43.7 mm (17.42 x 11.24 x 1.72″)
  • Weight: 4.30 kg
  • Weight with Rackmount brackets: 4.39 kg
  • Interfaces: (24) 10/100/1000 RJ45 Ports
  • Networking: (2) 1/10G SFP+ Ethernet Ports
  • Management: Ethernet In-Band
  • Power Method:
    – Universal Input: 100-240VAC/50-60 Hz
    – USP RPS DC Input: 52VDC, 7.69A; 11.5VDC, 2.61A
  • Power Supply: AC/DC, Internal, 450W
  • Supported Voltage Range: 100 to 240VAC
  • Max. Power Consumption (Excluding PoE Output): 50W
  • LEDs:
    – System: Status
    – RJ45 Data Ports: PoE; Speed/Link/Activity
    – SFP Data Ports: Link/Activity
  • ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature: -5 to 40° C (23 to 104° F)
  • Operating Humidity: 10 to 90% Noncondensing
  • Certifications: CE, FCC, IC

Sound level* (* Background noise level: 27.5 dBa)

  • 25% PoE, 25° C: 0.9 dBr
  • 50% PoE, 25° C: 7.3 dBr
  • 100% PoE, 40° C: 18.8 dBr

PoE

  • PoE Interfaces:
    – Ports 1-16: POE+ IEEE 802.3af/at, (pins 1, 2+; 3, 6-)
    – Ports 17-24: 60W PoE++ IEEE 802.3bt, (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 😎
  • Max. PoE Wattage per Port by PSE:
    – 802.3at: 32W
    – 802.3bt: 64W
  • Voltage Range 802.3af Mode: 44-57V
  • Voltage Range 802.3at Mode: 50-57V

Ubiquiti UniFi 24 Port Pro Switch (USW-Pro-24)

The Ubiquiti UniFi USW-Pro-24 is a fully managed Layer 3 switch with (24) Gigabit Ethernet ports. (2) 10G SFP+ uplinks offer link aggregation for higher capacity and increased availability. The UniFi Switch Pro 24 features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing, static routing, and DHCP server. The UniFi Switch Pro 24 is an ideal aggregation and access layer switch for any UniFi solution – it combines innovative near-silent cooling with UniFi SmartPower RPS power redundancy. UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere.

Ubiquiti UniFi USW-Pro-24 Switch key features

  • (24) Gigabit RJ45 ports
  • (2) 10G SFP+ ports
  • Layer 2 and Layer 3 features
  • UniFi SmartPower RPS DC input
  • Near-silent cooling
  • 1.3″ touchscreen display
  • Managed by UniFi Network Controller

Ubiquiti UniFi USW-Pro-24 Technical Specification

Product Specifications

  • Dimensions: 442.4 x 285.4 x 43.7 mm (17.42 x 11.24 x 1.72″)
  • Weight: 3.50 kg (7.72 lb)
  • Weight with brackets: 3.59 kg (7.92 lb)
  • Interfaces:
    – Networking: (24) 10/100/1000 RJ45 Ports, (2) 1/10G SFP+ Ethernet Ports
    – Management: Ethernet In-Band
  • Total Non-Blocking Throughput: 44 Gbps
  • Switching Capacity: 88 Gbps
  • Forwarding Rate: 65.472 Mpps
  • Power Method:
    – Universal Input: 100-240VAC,50/60 Hz
    – USP RPS DC Input: 11.5VDC, 2.61A
  • Power Supply: AC/DC, Internal, 36W
  • Voltage Range: 100 to 240VAC
  • Max Power Consumption: 30W
  • LEDs:
    – RJ45 Data Ports: Speed/Link/Activity
    – SFP+ Data Ports: Link/Activity
  • ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature: -5 to 45° C (23 to 113° F)
  • Operating Humidity: 10 to 90% Noncondensing
  • Certifications: CE, FCC, IC

Ubiquiti UniFi 24-Port PoE Switch (USW-24-POE)

The Ubiquiti UniFi USW-24-POE is a configurable, Gigabit Layer 2 switch with 24 Gigabit Ethernet ports including 16 auto-sensing 802.3at PoE+ ports, and two SFP ports.

Ubiquiti UniFi USW-24-POE Switch key features

  • 24x 10/100/1000 RJ45 Ports
  • 16x auto-sensing 802.3at PoE+ ports
  • 2x SFP ports
  • 1.3” touch LCM to provide status information
  • Compact, fanless design

The USW-24-POE provides Gigabit PoE links to RJ45 Ethernet devices and Gigabit fiber uplink options to enterprise networks. The switch features a 1.3″ touch LCM to provide status information. With a depth of 7.9″, the compact fanless design can be easily installed in a SOHO rack cabinet.

Managed and configured by the UniFi Network Controller with UniFi mobile app support, the USW-24-POE offers an extensive suite of advanced Layer 2 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.

Near silent cooling

Ubiquiti’s new airflow design reduces the need for fan usage.

New airflow design reduces need for fan usage

Powerful hardware and software

Ubiquiti UniFi Gen2 Switches offer a variety of features, including 10G SFP+ ports, PoE+ or PoE++ support, and Layer 3* switching capabilities. (*Layer 3 switching will be available in a future software release)

Powerful hardware and software

UniFi SmartPower RPS, USP-RPS, is Ubiquiti’s PSU failover system.

In the event of a UniFi switch power supply failure, the USP-RPS automatically supplies redundant power to the failed device. One UniFi SmartPower device can support up to 6 devices until the failed device is replaced.

UniFi SmartPower

Touch screen display

The 1.3″ touchscreen display allows easy monitoring and quick troubleshooting


Synchronised LCM displays Ubiquiti UniFi USW-24-POE Switch Technical Specification

Product Specifications

  • Dimensions: 442.4 x 200 x 43.7 mm (17.42 x 7.87 x 1.72″)
  • Weight: 3.00 kg (6.61 lb)
  • Weight with Brackets: 3.09 kg (6.81 lb)
  • Interfaces:
    – Networking: (24) 10/100/1000 RJ45 Ports, (2) 1G SFP Ethernet Ports
    – Management: Ethernet In-Band
  • Total Non-Blocking Throughput: 26 Gbps
  • Switching Capacity: 52 Gbps
  • Forwarding Rate: 38.69 Mpps
  • Power Method: 100-240VAC, 50/60 Hz, Universal Input
  • Power Supply: AC/DC, Internal, 120W
  • Voltage Range: 100 to 240VAC
  • Max Power Consumption (Excluding PoE Output): 25W
  • LEDs:
    – System: Status
    – RJ45 Data Ports: PoE; Speed/Link/Activity
    – SFP Data Ports: Link/Activity
  • ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature: -5 to 40° C (23 to 104° F)
  • Operating Humidity: 10 – 90% Noncondensing
  • Certifications: CE, FCC, IC

PoE

  • Total Available PoE: 95W
  • PoE Interfaces Ports 1-16: POE+ IEEE 802.3af/at (pins 1, 2+; 3, 6-)
  • Max. PoE Wattage per Port by PSE:
    – 802.3at: 32W
  • Voltage Range 802.3af Mode: 44-57V
  • Voltage Range 802.3at Mode: 50-57V

Ubiquiti UniFi Switch 24 500W Non-Blocking Backplane (US-24-500W)

The Ubiquiti UniFi Switch 24 500W is a fully managed twenty-four port PoE+ Gigabit switch that delivers robust performance, intelligent switching for growing networks.

Ubiquiti UniFi Switch 24 500W Key Features

  • Total Non-Blocking Throughput – 26 Gbps
  • SFP Ports – 2
  • Switching capacity: 52 Gbps
  • Forwarding rate: 38.69 Mpps
  • Maximum power consumption: 500W
  • Supports POE+ IEEE 802.3at/af and 24V Passive PoE

Switching Performance
The UniFi Switch 24 500W offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.

    Performance

PoE+ Flexibility
By default, the UniFi Switch 24 500W automatically detects 802.3af/at devices so they automatically receive PoE. For 24V passive PoE devices, manually enable 24V passive PoE using the UniFi Controller software.
                                            PoE
Fiber Connectivity
The UniFi Switch 24 500W provides fiber connectivity options for easy expansion of your networks. Each device also includes two SFP ports for uplinks of up to 1 Gbps.

Deployment Example
      Ubiquiti UniFi Switch 24 500W – Technical Specifications

General

  • Dimensions 485.04 x 44.45 x 285.6 mm (19.1 x 1.75 x 11.24″)
  • Weight 3.7 kg (8.16 lb)
  • Total Non-Blocking Throughput 26 Gbps
  • Switching Capacity 52 Gbps
  • Forwarding Rate 38.69 Mpps
  • Max. Power Consumption US-24-500W – 500W
  • Power Method 100-240VAC/50-60 Hz, Universal Input
  • Power Supply: AC/DC, Internal, 500W DC
  • LEDs Per Port
    Serial Console Port – N/A
    RJ45 Data Ports – PoE, Speed/Link/Activity
    SFP Data Ports – Speed/Link/Activity
  • Networking Interfaces (24) 10/100/1000 Mbps RJ45 Ethernet Ports (2) 1 Gbps SFP Ethernet Ports
  • Management Interface (1) RJ45 Serial Port, Ethernet In/Out Band
  • Certifications CE, FCC, IC
  • Rackmount Yes, 1U High
  • ESD/EMP Protection Air: ±24 kV, Contact: ±24 kV
  • Operating Temperature -5 to 40° C (23 to 104° F)
  • Operating Humidity 5 to 95% Noncondensing
  • Shock and Vibration ETSI300-019-1.4 Standard

PoE Per Port

  • PoE Interfaces POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
  • 24VDC Passive PoE (Pins 4, 5+; 7, 😎
  • Max. PoE+ Wattage per Port by PSE 34.2W
  • Voltage Range 802.3at Mode 50–57V
  • Max. Passive PoE Wattage per Port 17W
  • 24V Passive PoE Voltage Range 20-27V

Ubiquiti UniFi Switch 48 US-48 (NON-POE)

The US-48 (NON POE) UniFi Switch is a fully managed forty-eight port switch that delivers robust performance, intelligent switching for growing networks. The US-48 delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.

Ubiquiti UniFi Switch US-48 Key Features

  • 48 Gigabit RJ45 Ports
  • 2 SFP+ Ports
  • 2 SFP Ports
  • 1 Serial Console Port
  • Non-Blocking Throughput: 70 Gbps
  • Switching Capacity: 140 Gbps
  • Forwarding Rate: 104.16 Mpps
  • Maximum Power Consumption: 56W

Switching Performance
The UniFi Switch US-48 offers the forwarding capacity to simultaneously process traffic on all ports at line rate withoutany packet loss. For its total, non‑blocking throughput, the Ubiquiti UniFi Switch 48 model supports up to 70 Gbps.
Fiber Connectivity
The Ubiquiti UniFi Switch 48 adds two SFP+ports for high-capacity uplinks of up to 10 Gbps, so you can directly connect to a high‑performance storage server or deploy a long‑distance uplink to another switch.
Ubiquiti UniFi Switch US-48 – Technical Specifications

General

  • Dimensions 443 x 43 x 286 mm (17.44 x 1.69 x 11.26″)
  • Weight –
    Rack-Mount Brackets Excluded – 3.56 kg (7.85 lb)
    Rack-Mount Brackets Included – 3.65 kg (8.06 lb)
  • Networking Interfaces
    (48) 10/100/1000 Mbps RJ45 Ethernet Ports
    (2) 1/10 Gbps SFP+ Ethernet Ports
    (2) 1 Gbps SFP Ethernet Ports
  • Management Interface (1) RJ45 Serial Port Out-of-Band, Ethernet In-Band
  • Total Non-Blocking Throughput 70 Gbps
  • Switching Capacity 140 Gbps
  • Forwarding Rate 104.16 Mpps
  • Power Method 100-240VAC/50-60 Hz, Universal Input
  • Power Supply AC/DC, Internal, 56W DC
  • Max. Power Consumption 56W
  • LEDs per Port Speed/Link/Activity
  • Sound Level
    Fan Level: 0 – 34 dBa
    Fan Level: 1 – 37 dBa
  • ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
  • Rack Mount Yes, 1U High
  • Shock and Vibration ETSI300-019-1.4 Standard
  • Operating Temperature -5 to 40° C (23 to 104° F)
  • Operating Humidity 5 to 95% Noncondensing
  • Certifications CE, FCC, IC

Ubiquiti UniFi US-48-500W Switch

As part of the Ubiquiti UniFi line of products, the US-48-500W UniFi Switch is a fully managed 48 port PoE+ Gigabit switch that delivers robust performance, intelligent switching for growing networks. The US-48-500W delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.

Ubiquiti UniFi Switch 48 500W – US-48-500W Features

  • Total Non-Blocking Throughput – 70 Gbps
  • SFP+ Ports – 2
  • SFP Ports – 2
  • Switching capacity: 140 Gbps
  • Forwarding rate: 104.16 Mpps
  • Maximum power consumption: 500W
  • Supports POE+ IEEE 802.3at/af and 24V Passive PoE
  • Rackmountable
  • Product Model Number: US-48-500W

Switching Performance

The UniFi Switch US-48-500W offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.

PoE+ Flexibility

By default, the UniFi Switch automatically detects 802.3af/at devices so they automatically receive PoE. For 24V passive PoE devices, manually enable 24V passive PoE using the UniFi Controller software.

Fiber Connectivity

Selected Unifi switch models include either SFP or SFP+ ports for Uplink connectivity up to 10Gbps


UniFi Switch US-48-500W  deployment example Ubiquiti UniFi Switch 48 500W – Technical Specifications

US-48-500W

  • Dimensions 485.04 x 44.45 x 374.6 mm (19.1 x 1.75 x 13.69″)
  • Weight 5.3 kg (11.68 lb)
  • Total Non-Blocking Throughput 70 Gbps
  • Switching Capacity 140 Gbps
  • Forwarding Rate 104.16 Mpps
  • Max. Power Consumption US-48-500W: 500W, US-48-750W – 750W
  • Power Method 100-240VAC/50-60 Hz, Universal Input
  • Power Supply
    US-48-500W – AC/DC, Internal, 500W DC
    US-48-750W – AC/DC, Internal, 750W DC
  • LEDs Per Port
    Serial Console Port – N/A
    RJ45 Data Ports – PoE, Speed/Link/Activity
    SFP+/SFP Data Ports – Speed/Link/Activity
  • Networking Interfaces (48) 10/100/1000 Mbps RJ45 Ethernet Ports
    (2) 1/10 Gbps SFP+ Ethernet Ports
    (2) 1 Gbps SFP Ethernet Ports
  • Management Interface (1) RJ45 Serial Port, Ethernet In/Out Band
  • Certifications CE, FCC, IC
  • Rackmount Yes, 1U High
  • ESD/EMP Protection Air: ±24 kV, Contact: ±24 kV
  • Operating Temperature -5 to 40° C (23 to 104° F)
  • Operating Humidity 5 to 95% Noncondensing
  • Shock and Vibration ETSI300-019-1.4 Standard

PoE Per Port

  • PoE Interfaces POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
  • 24VDC Passive PoE (Pins 4, 5+; 7, 😎
  • Max. PoE+ Wattage per Port by PSE 34.2W
  • Voltage Range 802.3at Mode 50–57V
  • Max. Passive PoE Wattage per Port 17W
  • 24V Passive PoE Voltage Range 20-27V

Ubiquiti UniFi Switch 48 750W (US-48-750W)

The Ubiquiti UniFi US-48-750W is a fully managed 48 port PoE+ Gigabit switch that delivers robust performance and intelligent switching for growing networks. The US-48-750W delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.

Ubiquiti US-48-750W Key Features

  • (48) Gigabit RJ45 Ports
  • (2) SFP+ Ports
  • (2) SFP Ports
  • (1) Serial Console Port
  • Non-Blocking Throughput: 70 Gbps
  • Switching Capacity: 140 Gbps
  • Forwarding Rate: 104.16 Mpps
  • Maximum Power Consumption: 750W
  • Supports PoE+ IEEE 802.3at/af and 24V Passive PoE
  • Rack-Mountable

Powerful Enterprise Switch Models
The UniFi® Switch delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss. Total non-blocking throughput: up to 26 Gbps for 24-port models and up to 70 Gbps for US-48-750W.

Powerful Enterprise Switch

Advanced Port Management
Each switch port offers custom settings: port name, PoE, network/VLAN configuration, and operation mode (switching, mirroring, or aggregate) – as well as 802.1X Authentication and Radius VLAN support.

Advanced Port Management

Optical Fiber Connectivity
Two SFP ports support uplinks of up to 1 Gbps. For high-capacity uplinks, the US-48-750W includes two SFP+ ports for uplinks of up to 10 Gbps.

Optical Fiber Connectivity

Convenient PoE+ Support
The US-48-750W features auto-sensing IEEE 802.3af/at PoE to power multiple devices on the network.

Convenient PoE+ Support

Seamless Integration
The US-48-750W integrates seamlessly into the UniFi Software-Defined Networking (SDN) platform to create a highly scalable, end-to-end system of network devices across multiple locations — all controlled from a single interface.

Seamless Integration

Ubiquiti UniFi US-48-750W – Technical Specifications

General

  • Dimensions: 485 x 43.7 x 374.6 mm (19.09 x 1.72 x 14.75″)
  • Weight: 6.5 kg (14.3 lb)
  • Networking Interfaces:
    – (48) 10/100/1000 Mbps RJ45 Ethernet Ports
    – (2) 1/10 Gbps SFP+ Ethernet Ports
    – (2) 1 Gbps SFP Ethernet Ports
  • Management Interface: (1) RJ45 Serial Port Out-of-Band, Ethernet In-Band
  • Total Non-Blocking Throughput: 70 Gbps
  • Switching Capacity: 140 Gbps
  • Forwarding Rate: 104.16 Mpps
  • MAC Address Table: 16384
  • Maximum Aggregations: 6
  • Monitoring Sessions: 1
  • Maximum VLANs: 255
  • Power Method: 100-240VAC/50-60 Hz, Universal Input
  • Power Supply: AC/DC, Internal, 750W DC
  • Max. Power Consumption:
    – Including PoE Output: 750W
    – Excluding PoE Output: 64W
  • LEDs Per Port:
    – RJ45 Data Ports: PoE, Speed/Link/Activity
    – SFP Data Ports: Speed/Link/Activity
  • Sound Level (Background noise level: 27.5 dBa):
    – Fan Level 0: 12.1 dBr
    – Fan Level 1: 18.1 dBr
    – Fan Level 2: 21.6 dBr
    – Fan Level 3: 24.7 dBr
  • ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature: -5 to 40° C (23 to 104° F)
  • Operating Humidity: 5 to 95% Noncondensing
  • Certifications: CE, FCC, IC

PoE Per Port

  • PoE Interfaces:
    – PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
    – 24VDC Passive PoE (Pins 4, 5+; 7, 😎
  • Max. PoE+ Wattage per Port by PSE: 34.2W
  • Voltage Range 802.3at Mode: 50–57V
  • Max. Passive PoE Wattage per Port: 17W
  • 24V Passive PoE Voltage Range: 20-27V

Ubiquiti UniFi 48-Port PoE Switch (USW-48-PoE)

The Ubiquiti UniFi USW-48-PoE is a configurable Gigabit Layer 2 switch with 48 Gigabit Ethernet ports including 32 auto-sensing 802.3at PoE+ ports, and 4 SFP ports. It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network. The USW-48-PoE features a 1.3″ touch LCM to provide status.

Ubiquiti UniFi USW-48-PoE Switch key features

  • (48) Gigabit Ethernet Ports including (32) 802.3at PoE+
  • (4) 1G SFP Ports
  • 1.3″ touch LCM
  • Managed by UniFi Controller
  • 210W Power supply

Managed and configured by the UniFi Network Controller with UniFi mobile app support, the USW-48-PoE offers an extensive suite of advanced Layer 2 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.

Near silent cooling

Ubiquiti’s new airflow design reduces the need for fan usage.

New airflow design reduces need for fan usage

Touch screen display

The 1.3″ touchscreen display allows easy monitoring and quick troubleshooting


Synchronised LCM displays Ubiquiti UniFi USW-48-PoE Switch Technical Specification

Product Specifications

  • Dimensions: 442.4 x 285 x 43.7 mm (17.42 x 11.22 x 1.72″)
  • Weight: 4.52 kg (9.97 lb)
  • Weight with Brackets: 4.61 kg (10.16 lb)
  • Interfaces:
    – Networking: (48) 10/100/1000 RJ45 Ports, (4) 1G SFP Ethernet Ports
    – Management: Ethernet In-Band
  • Total Non-Blocking Throughput: 52 Gbps
  • Switching Capacity: 104 Gbps
  • Forwarding Rate: 77.38 Mpps
  • Power Method: 100-240VAC, 50/60 Hz, Universal Input
  • Power Supply: AC/DC, Internal, 240W
  • Voltage Range: 100 to 240VAC
  • Max Power Consumption (Excluding PoE Output): 45W
  • LEDs:
    – RJ45 Data Ports: PoE; Speed/Link/Activity
    – SFP Data Ports: Link/Activity
  • ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature: -5 to 40° C (23 to 104° F)
  • Operating Humidity: 10 – 90% Noncondensing
  • Certifications: CE, FCC, IC

PoE

  • Total Available PoE: 195W
  • PoE Interfaces Ports 1-32: PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
  • Max. PoE Wattage per Port by PSE:
    – 802.3at: 32W
  • Voltage Range 802.3af Mode: 44-57V
  • Voltage Range 802.3at Mode: 50-57V

Ubiquiti UniFi Switch Pro 48 (USW-Pro-48)

The Ubiquiti UniFi Switch Pro 48  is a fully managed Layer 3 switch with 48 Gigabit Ethernet ports. Four 10G SFP+ uplinks offer link aggregation for higher capacity and increased availability.

Ubiquiti UniFi USW-48-PoE Pro Switch key features

  • (48) Gigabit RJ45 ports
  • (4) 10G SFP+ ports
  • Layer 2 and Layer 3 features
  • UniFi SmartPower RPS DC input
  • Near-silent cooling
  • 1.3″ touchscreen display
  • Managed by UniFi Network Controller

The UniFi Switch Pro 48 features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing, static routing, and DHCP server. The UniFi Switch Pro 48 is an ideal aggregation and access layer switch for any UniFi solution. It combines innovative near-silent cooling with UniFi SmartPower RPS power redundancy. UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere.

Near silent cooling

Ubiquiti’s new airflow design reduces the need for fan usage.

New airflow design reduces need for fan usage


UniFi SmartPower RPS, USP-RPS, is Ubiquiti’s PSU failover system.

In the event of a UniFi switch power supply failure, the USP-RPS automatically supplies redundant power to the failed device. One UniFi SmartPower device can support up to 6 devices until the failed device is replaced.

UniFi SmartPower

Touch screen display

The 1.3″ touchscreen display allows easy monitoring and quick troubleshooting.

Synchronised LCM displays Ubiquiti UniFi Switch USW Pro 48 Technical Specification

Product Specifications

  • Dimensions: 442.4 x 285.4 x 43.7 mm(17.42 x 11.24 x 1.72″)
  • Weight: 4.00 kg (8.82 lb)
  • With Brackets: 44.09 kg (9.02 lb)
  • Interfaces:
    – Networking: (48) 10/100/1000 RJ45 Ports
    – Management: (4) 1/10G SFP+ Ethernet Ports Ethernet In-Band
  • Total Non-Blocking Throughput: 88 Gbps
  • Switching Capacity: 176 Gbps
  • Forwarding Rate: 130.944 Mpps
  • Power Method:
    – Universal Input: 100-240VAC, 50/60 Hz
    – USP RPS DC Input: 11.5VDC, 5.22A
  • Power Supply: AC/DC, Internal, 60W
  • Voltage Range: 100 to 240VAC
  • Max Power Consumption: 60W
  • LEDs
    – RJ45 Data Ports: Speed/Link/Activity
    – SFP+ Data Ports: Link/Activity
  • ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature-5 to 45° C (23 to 113° F)
  • Operating Humidity10 – 90% Noncondensing
  • Certifications: CE, FCC, IC

Ubiquiti UniFi 48 Port PoE Pro Switch (USW-Pro-48-POE)

The Ubiquiti UniFi USW Pro 48 POE is a Gen2, configurable, Gigabit Layer 2 and Layer 3 switch with auto-sensing 802.3at PoE+ and 802.3bt PoE++.

Ubiquiti UniFi USW-48-PoE Pro Switch key features

  • 48 x 10/100/1000 RJ45 ports
  • (1-40) IEEE 802.3af/at PoE+ ports
  • (41-48) 60W IEEE 802.3bt PoE++ ports
  • 4 x 1/10G SFP+ Ethernet Ports
  • 1.3” touch LCM to provide status information
  • Near-silent cooling

40 PoE+ and eight PoE++ RJ45 ethernet ports have total 600W PoE budget, and four SFP+ ports offer 10Gbps uplink options. Other benefits include near-silent cooling and a 1.3″ touch screen LCM display.

Note: Layer3 will be included in later software release.

Near silent cooling

Ubiquiti’s new airflow design reduces the need for fan usage.

New airflow design reduces need for fan usage

Powerful hardware and software

Ubiquiti UniFi Gen2 Switches offer a variety of features, including 10G SFP+ ports, PoE+ or PoE++ support, and Layer 3* switching capabilities (*Layer 3 switching will be available in a future software release).

Powerful hardware and software

UniFi SmartPower RPS, USP-RPS, is Ubiquiti’s PSU failover system.

In the event of a UniFi switch power supply failure, the USP-RPS automatically supplies redundant power to the failed device. One UniFi SmartPower device can support up to 6 devices until the failed device is replaced.

UniFi SmartPower

Touch screen display

The 1.3″ touchscreen display allows easy monitoring and quick troubleshooting.

Synchronised LCM displays Ubiquiti UniFi UniFi USW Pro 48 POE Technical Specification

Product Specifications

  • Dimensions: 442.4 x 399.6 x 43.7 mm (17.42 x 15.73 x 1.72″)
  • Weight: 6.25 kg (13.78 lb)
  • Weight with Rackmount Brackets: 6.34 kg (13.98 lb)
  • Interfaces: (48) 10/100/1000 RJ45 Ports
  • Networking: (4) 1/10G SFP+ Ethernet Ports
  • Management: Ethernet In-Band
  • Power Method:
    – Universal Input: 100-240VAC/50-60 Hz
    – USP RPS DC Input: 52VDC, 11.54A; 11.5VDC, 5.22A
  • Power Supply: AC/DC, Internal, 120W
  • Supported Voltage Range: 100 to 240VAC
  • Max. Power Consumption (Excluding PoE Output): 60W
  • LEDs:
    – System: Status
    – RJ45 Data Ports: PoE; Speed/Link/Activity
    – SFP Data Ports: Link/Activity
  • ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature: -5 to 40° C (23 to 104° F)
  • Operating Humidity: 10 to 90% Noncondensing
  • Certifications: CE, FCC, IC

Sound level* (* Background noise level: 27.5 dBa)

  • 25% PoE, 25° C: 0.9 dBr
  • 50% PoE, 25° C: 7.3 dBr
  • 100% PoE, 40° C: 22.5 dBr

PoE

  • PoE Interfaces:
    – Ports 1-40: POE+ IEEE 802.3af/at, (pins 1, 2+; 3, 6-)
    – Ports 41-48: 60W PoE++ IEEE 802.3bt, (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 😎
  • Max. PoE Wattage per Port by PSE:
    – 802.3at: 32W
    – 802.3bt: 64W
  • Voltage Range 802.3af Mode: 44-57V
  • Voltage Range 802.3at Mode: 50-57V

Ubiquiti UniFi Industrial Switch 10-Port (USW-Industrial)

The Ubiquiti UniFi USW-Industrial is a managed, plenum-rated, Gigabit Layer 2 switch with auto-sensing 802.3bt PoE++ support.

Ubiquiti UniFi USW-Industrial Key Features

  • Auto-Sensing IEEE 802.3af/at/bt PoE
  • Fanless Industrial-Grade Design
  • Plenum-Rated Form Factor
  • Switching Performance
  • PoE++ Flexibility
  • Ruggedised Industrial Design

PoE++ Flexibility

Eight ports offer auto-sensing 802.3af/at/bt PoE to provide up to 60W of power (per port) to power multiple devices on the network.

PoE++ Flexibility

Ruggedised Industrial Design

The fanless UniFi USW-Industrial is plenum-rated so it can be installed in a horizontal or vertical orientation in plenum spaces. Its die-cast aluminium enclosure has a black, powder coated finish for increased durability and greater resistance to corrosion. It can operate at full 450W power in environments up to 50° C.

rugged industrial design

Compatible Products

The USW-Industrial powers a variety of products, including the UniFi AC Mesh AP, UniFi Video Camera G4 Pro, and multiple UniFi LED Panels, which use 802.3at PoE+.

Compatible Products

Seamless Integration

A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralised interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.

seamless integration

Ubiquiti UniFi USW-Industrial Technical Specification

Product Specifications

  • Dimensions: 254 x 235 x 60 mm (10 x 9.25 x 2.36″)
  • Weight: 3.85 kg (8.49 lb)
  • Enclosure Characteristics: Die-Cast Aluminium (ADC12) with Black Powder Coated Finish
  • Interfaces:
    – Networking: (8) 10/100/1000 802.3bt PoE RJ45 Ports, (2) 10/100/1000 RJ45 Ports
    – Management: Ethernet In-Band
  • Total Non-Blocking Throughput: 10 Gbps
  • Switching Capacity: 20 Gbps
  • Forwarding Rate: 14.88 Mpps
  • Power Method: 100 – 240 VAC, 50/60 Hz Universal Input
  • Power Supply: AC/DC, Internal, 450W DC
  • Supported Voltage Range: AC Input: 100 to 240VAC, Max. 6A
  • Max. Power Consumption (Excluding PoE Output): 20W
  • LEDs:
    – System: Status
    – RJ45 Ports: PoE, Speed/Link/Activity
  • ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV
  • Shock and Vibration: ETSI300-019-1.4 Standard
  • Operating Temperature:
    – Internal AC/DC @ 450W: -40 to 50° C (-40 to 122° F)
    – Internal AC/DC @ 240W: -40 to 60° C (-40 to 140° F)
  • Operating Humidity: 5 to 95% Noncondensing
  • Certifications: FCC, IC

PoE

  • PoE Interfaces: PoE++ IEEE 802.3bt (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 😎
  • Max. PoE Wattage per Port by PSE: 802.3bt 60W
  • Voltage Range 802.3 PoE Mode: 50-57V
  • Max. Total PoE Power Budget: 430W

Ubiquiti UniFi Security Gateway Router (USG)

The USG Ubiquiti UniFi Security Gateway, is an enterprise Gateway router with Gigabit Ethernet that combines advanced security features with high performance routing technology in a compact and cost-effective unit.

USG is wall-mountable with a dual-core, 500 MHz processor for standard hardware-accelerated performance.

Ubiquiti UniFi Security Gateway USG Key Features

  • 3 Gigabit Ethernet ports
  • 1 million packets per second for 64-byte packets
  • 3 Gbps total line rate for packets 512 MB or larger
  • Secure off-site management and monitoring
  • CLI management for advanced users
  • Silent, fanless operation

Capable of routing up to 1 million packets per second, the UniFi USG can be easily configured through the intuitive UniFi Controller software, which also manages the UniFi Access Points for wireless networking.

Integration with UniFi Controller
The UniFi® Controller software conducts device discovery, provisioning, and management of the UniFi USG and other UniFi devices through a single, centralised interface.
Integration with UniFi Controller

Powerful Firewall Performance
The UniFi USG offers advanced firewall policies to protect your network and its data.
Powerful Firewall Performance

Convenient VLAN Support
The UniFi USG can create virtual network segments for security and network traffic management.
Convenient VLAN Support

VPN Server for Secure Communications
A site-to-site VPN secures and encrypts private data communications traveling over the Internet.
VPN Server for Secure Communications

QoS for Enterprise VoIP
Top QoS priority is assigned to voice/video call traffic for clear calls and lag-free, video streaming.

QoS for Enterprise VoIP

Ubiquiti UniFi Security Gateway (USG) – Technical Specifications

General

  • Dimensions: 135 x 135 x 28.3 mm (5.32 x 5.32 x 1.11″)
  • Weight: 366 g (12.9 oz)
  • Max. Power Consumption: 7W
  • Power Supply: 12VDC, 1A Power Adapter (Included)
  • Power Input: 9 to 24VDC, Supported Voltage Range
  • LEDs:
    – System: Status
    – Serial Console Port: Power
    – Data Ports: Speed/Link/Activity
  • Networking Interfaces:
    – Serial Console Port: (1) RJ45 Serial Port
    – Data Ports: (3) 10/100/1000 Ethernet Ports*
  • Layer 3 Forwarding Performance:
    – Packet Size: 64 Bytes: 1,000,000 pps
    – Packet Size: 512 Bytes or Larger: 3 Gbps (Line Rate)
  • Processor: Dual-Core 500 MHz, MIPS64 with Hardware Acceleration for Packet Processing
  • System Memory: 512 MB DDR2 RAM
  • On-Board Flash Storage: 2 GB
  • Certifications: CE, FCC, IC
  • Wall-Mountable: Yes
  • Operating Temperature: -10 to 45° C (14 to 113° F)
  • Operating Humidity: 10 to 90% Noncondensing

*VOIP port is available for port remapping in UniFi v5.

Ubiquiti UniFi Dream Machine Pro Enterprise Security Gateway and Network Appliance with 10G SFP+ (UDM-PRO)

The Ubiquiti UDM-PRO is an all-in-one network appliance for a scalable network in an office, retail, or hospitality environment. Powered by a fast 1.7 GHz quad-core processor, the UDM Pro combines multiple functions into a single device: Advanced Security Gateway with Built-in Switch, Dual WAN Ports: One 10G SFP+ and One Gigabit RJ45, One 10G SFP+ LAN Port, Embedded Enterprise Software: UniFi Network and 3.5″ HDD Bay for NVR Storage (2.5″ HDD also supported).

Ubiquiti UDM Key Features

  • All-in-one 1U rack appliance for small to medium sized businesses
  • Combines new UniFi OS with 8-port switch and security gateway
  • UniFi Protect video surveillance NVR with off-the-shelf 3.5″ HDD support
  • 8-port Gigabit Switch with 1 Gbps RJ45 and 10G SFP+ LAN
  • Enterprise-class IPS/IDS, DPI, and Wi-Fi AI capabilities
  • Powered by fast 1.7 GHz quad-core processor

Security Gateway
The enterprise-class security gateway combines routing, 10 Gbps SFP+ WAN, application visibility, VPN services, and 3.5 Gbps full threat management throughput into a single device.
Security Gateway

Managed Switch
Fully managed switch with 10 Gbps SFP+ downlink and eight RJ45 GbE ports for scaling up.

UniFi Network
Integrated network management system for all network elements with an easy-to-use and modern user interface. Wi-Fi AI automatically optimises the Wi-Fi network.

UniFi Protect
Professional-grade video surveillance systemand NVR with integrated 3.5″/2.5″ HDD bay for scalable storage.
UniFi Protect

Advanced Redundancy
The UDM Pro features dual WAN ports with failover and U-LTE1 backup connectivity to ensure reliable access to the internet. UniFi SmartPower USP-RPS2 provides redundant power in the event of AC power loss.

Advanced Redundancy
UniFi Enterprise Architecture Evolves with UniFi OS
The new UniFi Cloud portal provides simple access to all controllers and an increasing number of UniFi applications.

UniFi OS
Seamless Network Integration
Use the UniFi Dream Machine Pro as your network controller.

Seamless IntegrationUbiquiti UDM Technical Specifications

Overview

  • Dimensions: 442.4 x 43.7 x 285.6 mm (17.42 x 1.72 x 11.24″)
  • Weight: 3.90 kg (8.60 lb)
  • Weight with Brackets: 3.99 kg (8.80 lb)
  • Interfaces:
    – Networking: (8) 10/100/1000 RJ45 LAN Ports, (1) 10/100/1000 RJ45 WAN Port, (1) 1/10G SFP+ LAN Port, (1) 1/10G SFP+ WAN Port
    – Management: Ethernet In-Band, (1) Bluetooth BLE
  • IDS/IPS Throughput: 3.5 Gbps*
  • Processor: Quad ARM Cortex-A57 Core at 1.7 GHz
  • System Memory: 4 GB DDR4
  • On-Board Flash Storage: 16 GB eMMC
  • Maximum Power Consumption: 33W
  • Voltage Range: 100 to 240VAC
  • Power Method:
    – (1) Universal AC Input, 100-240VAC, 50/60 Hz
    – (1) RPS DC Input
  • Power Supply: Internal 50W/12V
  • LEDs:
    – HDD: Activity
    – RJ45: Link/Speed/Activity
    – SFP+: Link/Speed/Activity
  • ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
  • Operating Temperature: -10 to 40° C (14 to 104° F)
  • Operating Humidity: 5 to 95% Noncondensing
  • Certifications: CE, FCC, IC

Ubiquiti UniFi SmartPower Redundant Power System (USP-RPS)

The Ubiquiti UniFi USP-RPS is a proprietary redundant power system designed to protect up to six UniFi SmartPower supported devices from sudden power supply module failure. The USP-RPS continually monitors all attached devices. In the event of an internal AC/DC power supply failure, failover is automatic so your network continues to operate with no interruption in service. With a 950W DC power budget, the USP-RPS can protect a variety of high-power devices, including UniFi PoE switches. An integrated 1.3″ colour touchscreen LCM displays system information for convenient monitoring.

Ubiquiti UniFi USP-RPS Key Features

  • 6x USP DC output ports
  • 1x Ethernet port
  • 1U Rackmountable (kit included)
  • 1.3″ Touchscreen display with status information
  • Managed by UniFi Network Controller version: 5.12.11 or later

Ubiquiti UniFi USP-RPS – Technical Specifications

General

  • Dimensions: 442.40 x 325.60 x 43.70 mm (17.42 x 12.82 x 1.72″)
  • Weight: 5.500 kg (12.13 lb)
  • Weight With Mount Brackets: 5.590 kg (12.32 lb)
  • Interfaces:
    – Networking: (1) 10/100/1000 Mbps RJ45 Port
    – Management: Ethernet In-Band
    – Power Output: (6) RPS DC Ports
  • Max. Power Consumption: 995W
  • Power Method: (1) Universal AC Input, 100 to 240VAC
  • Power Supply:
    – Internal 350W AC/DC
    – Internal 645W AC/DC
  • Supported Voltage Range: 100 – 240VAC
  • Display: 1.3″ Colour Touch Panel
  • LED:
    – System: Status
    – RJ45: Link/Activity
    – USP RPS: Activity
  • ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
  • Operating Temperature: 5 to 45° C (23 to 113° F)
  • Operating Humidity: 10 to 90% Noncondensing
  • Certifications: CE, FCC, IC

RPS

  • Total Output Power:
    – 52VDC: 11.54A (600W)
    – 11.5VDC: 30.44A (350W)
  • Max. Output Power per RPS Port:
    – 52VDC: 11.54A (600W)
    – 11.5VDC: 30.44A (350W)

Power Buget*

  • UDM-Pro:
    – 52V: 0
    – 12V: 50W
  • USW-Pro-24:
    – 52V: 0
    – 12V: 30W
  • USW-Pro-24-PoE:
    – 52V: 400W
    – 12V: 30W
  • USW-Pro-48-PoE:
    – 52V: 600W
    – 12V: 50W

USP-Cable

  • Length: 1.5 m (4.9 ft)
  • Conductor Type: Tinned Copper
  • Conductor Wire Gauge: (18) 16 AWG, (6) 24 AWG
  • Insulation Type: PVC
  • Insulation Thickness: 0.35 mm (0.014″)
  • Insulation Diameter: 2.0 mm (0.079″)
  • Jacket Material: PVC
  • Jacket Outside Diameter: 9.5 × 23.0 mm (0.374 x 0.905″)

Ubiquiti UniFi Switch Aggregation (USW-Aggregation)

The Ubiquiti UniFi Aggregation Switch is a managed Layer 2 switch with eight 10G SFP+ ports. Featuring a compact 4.7″ depth and fanless design, it supports high-bandwidth links to provide link aggregation for higher capacity and increased availability.

Ubiquiti UniFi Switch Aggregation key features

  • (8) 10G SFP+ Ports
  • 160 Gbps switching capacity
  • 1.3″ Touchscreen with AR switch management
  • Fanless, 4.7″ depth compact enclosure
  • 1U Rackmountable (kit included)
  • Managed by UniFi Network Controller (version: 5.43.13 or higher)

Ubiquiti Switch Aggregation Technical Specification

Mechanical

  • Dimensions: 442.4 x 120 x 43.7 mm (17.42 x 4.72 x 1.72″)
  • Weight
    – Without Mount 2.65 kg (5.84 lb)
    – With Mount 2.74 kg (6.04 lb)
  • Enclosure Material: SGCC Steel

Hardware

  • Total Non-Blocking Throughput: 80 Gbps
  • Switching Capacity: 160 Gbps
  • Forwarding Rate: 119.04 Mpps
  • Max. Power Consumption: 30W
  • Power Method: Universal AC Input: 100-240VAC, 50/60 Hz
  • Power Supply: AC/DC, Internal, 36W
  • Management Interface: Ethernet In-Band
  • Modes: SMB Layer 2 Gigabit Ethernet Switch
  • ESD/EMP Protection: Air: ± 16kV, Contact: ± 12kV
  • Operating Temperature: -5 to 40° C (23 to 104° F)
  • Operating Humidity: 10 – 90% Noncondensing
  • Certifications: CE, FCC, IC

LED

System

  • (1) Bootup Animation: Bootup in Progress
  • Firmware Upgrade Icon: Firmware Upgrading
  • Steady White: Factory Defaults, Awaiting Adoption
  • Steady Blue: Device is Adopted
  • SFP+: White: 10G, 1G

Ubiquiti UniFi Switch Enterprise (USW-Enterprise-24-PoE)

The Ubiquiti UniFi Switch Enterprise USW-Enterprise-24-PoE is a managed Layer 3 switch with twelve 2.5G RJ45 ports with PoE+ for WiFi 6 APs, twelve Gigabit RJ45 ports with PoE+, and two 10G SFP+ ports for fiber uplinks.

Ubiquiti UniFi Switch USW-Enterprise-24-PoE key features

  • 12 x 2.5G 802.3af/at PoE+ RJ45 ports
  • 12 x 1G 802.3af/at PoE+ RJ45 ports
  • Two 10G SFP+ ports
  • 400W total PoE capacity
  • 1.3″ touchscreen with AR switch management
  • UniFi SmartPower RPS DC input
  • Managed with the UniFi Network Application (web and mobile): Version: 5.14.12 or higher

The USW-Enterprise-24-PoE is a configurable Gigabit Layer 3 switch with auto-sensing 802.3at PoE+. It offers (12) 2.5G RJ45 Ethernet ports, (12) 1G RJ45 Ethernet ports, and (2) 10G SFP+ ports, providing 2.5G PoE links to your WiFi 6 APs and 10G fiber uplinks to your network.

It features include a 1.3″ touchscreen, single-row RJ45 port layout for easy patch panel cable management, and UniFi SmartPower Redundant Power System* (USP-RPS) support for intelligent protection from internal PSU interruption or failure.

Ubiquiti UniFi Switch USW-Enterprise-24-PoE Technical Specification

Mechanical

  • Dimensions: 442.4 x 43.7 x 325 mm (17.4 x 1.7 x 12.8″)
  • Weight
    – Without Mount: 5.11 kg (11.27 lb)
    – With Mount: 5.2 kg (11.46 lb)
  • Enclosure Material: SGCC Steel
  • Mount Material: SGCC Steel

Hardware

  • Total Non-Blocking Throughput: 62 Gbps
  • Switching Capacity: 124 Gbps
  • Forwarding Rate: 92.25 Mpps
  • Max. Power Consumption: 550W
  • Power Method:
    – Universal AC Input: 100-240VAC, 50/60 Hz
    – USP-RPS DC input: 52VDC, 7.7A; 11.5VDC, 8.7A
  • Power Supply: AC/DC, Internal, 550W
  • Management Interface: Ethernet In-Band
  • Networking Interfaces
    – 12 x 10/100/1000 Mbps RJ45 Ethernet
    – 12 x 100/1000/2500 Mbps RJ45 Ethernet
  • SFP+ Interfaces: 2 x 1/10G SFP+
  • PoE Interfaces: 24 x PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
  • Max. PoE+ Wattage per Port by PSE 34.2W
  • Voltage Range 802.3af Mode 44 to 57V
  • Voltage Range 802.3at Mode 50 to 57V
  • Services SMB Layer 3 PoE Gigabit Ethernet Switch
  • ESD/EMP Protection Air: ± 16 kV, Contact: ± 12 kV
  • Operating Temperature -5 to 40° C (23 to 104° F)
  • Operating Humidity 10 – 95% Noncondensing
  • Certifications CE, FCC, IC

LEDs

System

  • Bootup Animation: Bootup in Progress
  • Firmware Upgrade Icon: Firmware Upgrading
  • Steady White: Factory Defaults, Awaiting Adoption
  • Steady Blue: Device is Adopted

Ethernet

  • White: Link or activity

SFP+

  • White: Link or activity

Ubiquiti UniFi Switch Enterprise 48 PoE (USW-Enterprise-48-PoE)

The Ubiquiti UniFi Switch USW-Enterprise-48-PoE is a fully managed, Layer 3 switch with 48 x 2.5GbE RJ45 Ethernet ports with PoE+ for WiFi 6 APs, and four 10GbE SFP+ ports for fiber uplinks.

Ubiquiti UniFi Switch USW-Enterprise-48-PoE key features

  • 48 x 2.5GbE 802.3af/at PoE+ RJ45 ports
  • 4 x 10GbE SFP+ ports
  • USP RPS support for redundant power backup
  • 400W total PoE capacity
  • 1.3″ LCM touchscreen with AR switch management

The USW-Enterprise-48-PoE is a configurable, Layer 3 switch with auto-sensing 802.3at PoE+. It offers 48 x 2.5GbE RJ45 Ethernet ports, and four 10GbE SFP+ ports, providing 2.5GbE PoE links to your WiFi 6 APs and 10GbE fiber uplinks to your network. The USW Enterprise 48 PoE also features a 1.3″ LCM touchscreen. Easily managed in the UniFi Network application (web or mobile), the USW Enterprise 48 PoE offers Layer 3 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port. The UniFi Network application (web or mobile) also allow admins to configure and monitor the USW Enterprise 48 PoE from anywhere via an intuitively designed user interface.

Ubiquiti UniFi Switch USW-Enterprise-48-PoE Technical Specification

Mechanical

  • Dimensions: 442 x 44 x 399 mm(17.4 x 1.7 x 15.7″)
  • Weight
    – Without Mount:  6.2 kg (13.67 lb)
    – With Mount: 6.3 kg (13.89 lb)
  • Enclosure Material: SGCC Steel
  • Mount Material: SGCC Steel

Hardware

  • Total Non-Blocking Throughput: 160 Gbps
  • Switching Capacity: 320 Gbps
  • Forwarding Rate: 238.095 Mpps
  • Max. Power Consumption: 100W
  • Power Method:
    – Universal AC Input: 100-240VAC, 8.5A Max, 50/60 Hz
    – USP-RPS DC input: 52VDC, 7.7A; 11.5VDC, 8.7A
  • Power Supply: AC/DC, Internal, 100-240V, 8.5A Max
  • Management Interface: Ethernet In-Band
  • Networking Interfaces: 48 x 100/1000/2500 Mbps RJ45 Ethernet
  • SFP+ Interfaces: 4 x 1/10G SFP+
  • PoE Interfaces: 48 x PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
  • Total available PoE: 400W
  • Max. PoE+ Wattage per Port by PSE: 34.2W
  • Voltage Range 802.3af Mode: 44 to 57V
  • Voltage Range 802.3at Mode: 50 to 57V
  • Services: SMB Layer 3 PoE Gigabit Ethernet Switch
  • ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
  • LCM Display:
    – 1.3″ Touchscreen
    – Bootup Animation: Bootup in Progress
    – Firmware Upgrade Icon: Firmware Upgrading
    – Steady White: Factory Defaults, Awaiting Adoption
    – Steady Blue: Device is Adopted
  • Button: Factory reset
  • Operating Temperature -5 to 40° C (23 to 104° F)
  • Operating Humidity 10 – 90% Noncondensing
  • Certifications CE, FCC, IC

LED

  • Ethernet: White: Link or Activity
  • SFP+: White: Link or Activity

Ubiquiti UniFi Switch Flex XG (USW-FLEX-XG)

The Ubiquiti UniFi Switch USW-FLEX-XG is a high-performance, managed Layer 2 multi-gigabit switch with one Gigabit PoE input and four 10GbE Ethernet ports.


Ubiquiti UniFi Switch USW-FLEX XG Key Features

  • One Gigabit PoE input port
  • Four 10GbE RJ45 ports
  • Compact, slim housing
  • Managed with the UniFi Network Application (web and mobile): Version 6.1.67 or higher.

Easily expand your network with the UniFi Switch Flex XG (USW Flex XG), a highly configurable, managed, 10GbE Layer 2 switch with five RJ45 Gigabit Ethernet ports, including one PoE Gigabit input and four 10GbE RJ45 Ethernet ports. Sporting a compact, slim design, the USW Flex XG delivers high-performance switching in any environment and is centrally managed in the UniFi Network application.Ubiquiti UniFi Switch USW-FLEX-XG – Technical Specifications

General

  • Dimensions: 135 x 185 x 32 mm (5.31 x 7.28 x 1.27″)
  • Weight: 1.2 kg (2.65 lb)
  • Enclosure material: Polycarbonate

Hardware

  • Total Non-Blocking Throughput: 41 Gbps
  • Switching Capacity: 82 Gbps
  • Forwarding Rate: 61.012 Mpps
  • Max Power Consumption: 25W
  • Power Method:
    – 802.3at PoE, 50-57VDC, 25W
    – One USB Type-C, 5VDC, 5A
  • Power Supply
    – 802.3at PoE (Pins 1, 2+/3, 6- or 4, 5+/7, 😎
    – AC/DC Power Adapter, 5VDC, 5A, 1.5 m Cord (Included)
  • Supported Voltage Range: 90 to 264VAC (Adapter)
  • Management Interface: Ethernet In-Band
  • Networking Interfaces:
    – One 10/100/1000 Mbps RJ45 Ethernet
    – Four 1/2.5/5/10 Gbps RJ45 Ethernet
  • Services: SMB Layer 2 Gigabit Ethernet Switch
  • ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
  • Button: Factory Reset
  • Operating Temperature: -5 to 45° C (23 to 113° F)
  • Operating Humidity: 10 – 90% Noncondensing
  • Certifications: CE, FCC, IC

LEDs

System

  • One Power, Blue/White
  • Flashing White: Bootup in Progress
  • Flashing Blue: Firmware Upgrading
  • Steady White: Factory Defaults, Awaiting Adoption
  • Steady Blue: Device is Adopted

Ethernet

  • White: Link or Activity

Ubiquiti UniFi Switch Pro Aggregation (USW-Pro-Aggregation)

The Ubiquiti UniFi Switch Pro Aggregation is a fully managed, Layer 3 switch with (4) 25G SFP28 ports and (28) 10G SFP+ ports.


Ubiquiti UniFi Switch Pro Aggregation key features

  • 28 x 10 Gbps SFP+ ports
  • 4 x 25 Gbps SFP28 ports
  • 760 Gbps switching capacity
  • 1.3” touchscreen with AR switch management
  • Backup 12V DC input connector, SmartPower RPS
  • Managed with the UniFi Network Application: Version 6.1.25 and higher

The UniFi Switch Pro Aggregation utilises high-bandwidth links to create link aggregation that enhances its switching capacity. The UniFi Switch Pro Aggregation is managed with the UniFi Network application (web and mobile), allowing you to easily build, scale, and monitor your enterprise networks. Ubiquiti UniFi Switch Pro Aggregation Technical Specification

Mechanical

  • Dimensions: 442 x 325 x 44 mm (17.4 x 12.8 x 1.7″)
  • Weight
    – Without Mount: 4.6 kg (10.14 lb)
    – With Mount: 4.7 kg (10.36 lb)
  • Enclosure Material: SGCC Steel

Hardware

  • Total Non-Blocking Throughput: 380 Gbps
  • Switching Capacity: 760 Gbps
  • Forwarding Rate: 565.44 Mpps
  • Max. Power Consumption: 100W
  • Power Method:
    – Universal AC Input: 100-240VAC, 50/60 Hz
    – USP-RPS DC input, 11.5VDC, 8.7A
  • Network Interface:
    – 28 x 1/10 Gbps SFP+ Ethernet
    – 4 x 1/10/25 Gbps SFP28 Ethernet*
  • LCM Display:
    – 1.3″ Touchscreen
    – Bootup Animation: Bootup in Progress
    – Firmware Upgrade Icon: Firmware Upgrading
    – Steady White: Factory Defaults, Awaiting Adoption
    – Steady Blue: Device is Adopted
  • LEDS: SFP28/SFP+: White, Link and Activity
  • Management Interface: Ethernet In-Band
  • Modes: SMB Layer 3 10/25 G Fiber Switch
  • ESD/EMP Protection: Air: ± 16kV, Contact: ± 12kV
  • Operating Temperature: -5 to 40° C (23 to 104° F)
  • Operating Humidity: 10 – 90% Noncondensing
  • Certifications: CE, FCC, IC
Out of stock
KSh18,000.00 Exc. Tax
Sale!
KSh24,000.00 Exc. Tax
Sale!
KSh25,000.00 Exc. Tax
Sale!
KSh25,000.00 Exc. Tax
KSh27,500.00 Exc. Tax
KSh28,000.00 Exc. Tax
Out of stock
KSh29,000.00 Exc. Tax

Ethernet Network Switches

Ubiquiti TS-8-PRO ToughSwitch 8 Port

KSh30,000.00 Exc. Tax
Sale!
KSh30,000.00 Exc. Tax
KSh40,000.00 Exc. Tax
KSh51,000.00 Exc. Tax
KSh52,000.00 Exc. Tax
KSh54,000.00 Exc. Tax
KSh55,000.00 Exc. Tax
KSh56,000.00 Exc. Tax
KSh60,000.00 Exc. Tax
Sale!
Out of stock
KSh63,000.00 Exc. Tax
KSh70,000.00 Exc. Tax
Sale!
KSh70,000.00 Exc. Tax

Ethernet Network Switches

Ubiquiti EdgeSwitch 16 XG – ES-16-XG

KSh71,000.00 Exc. Tax
KSh72,000.00 Exc. Tax
Sale!
KSh100,000.00 Exc. Tax
KSh105,000.00 Exc. Tax
KSh110,000.00 Exc. Tax
Sale!
KSh120,000.00 Exc. Tax
KSh130,000.00 Exc. Tax
