ES-24-250W Ubiquiti EdgeSwitch 24-Port PoE Switch 250W
KSh75,000.00 Excl. Tax
Get superior switching performance with the Ubiquiti EdgeSwitch ES-24-250W – a fully managed, Layer 2/3 switch offering 24 Gigabit PoE+ ports, 2 SFP uplinks, and a 250W power budget. Ideal for businesses, ISPs, and surveillance networks in Kenya.
Genuine product Secure checkout Warranty and order support Discounted Prices
Ubiquiti EdgeSwitch ES-24-250W – 24-Port Managed PoE+ Gigabit Switch with 250W Power Budget
The ES-24-250W Ubiquiti EdgeSwitch 24-Port PoE Switch 250Wis 24-Port, Managed PoE+ Gigabit switch with 250W non-blocking throughput switching performance, Gigabit Ethernet RJ45 and SFP+SFP Ports and Auto-Sensing IEEE 802.3af/at PoE. The ES-24-250W Ubiquiti switch belongs to the EdgeMax series which includes functional and reliable solutions that meet the requirements of even the most demanding users.
ES-24-250W is a manageable layer-2 and layer-3 switch. It is distinguished by efficient, reliable workmanship, a durable case, PoE+ support and an intelligent switching system for developing networks.
Reliability
The device is equipped with 24 RJ-45 Gigabit Ethernet (10/100/1000) type ports and 2 SFP ports. It is IEEE 802.3af and IEEE 802.3at standard compliant. The routing/switching capacity is 52 Gbit/s.
Installation
Ubiquiti products are installed in racks. Certificates: CE, FCC and IC. Its output requirements are 100-240 V power, 50/60 Hz frequency. It weighs 3700 g with 485.04 x 285.6 x 44.45 mm size.
Key Features
- L2/L3 switch
- 24 Gigabit Ethernet (10/100/1000) ports
- 2 SFP module slots
- 52 Gbit/s switching capacity
- 38.69 Mpps forwarding rate
- rack-mounted switch
Comparison
| ES-24-250W | ES-24-500W | ES-48-500W | ES-48-750W | |
| Total Non-Blocking Throughput | 26 Gbps | 26 Gbps | 70 Gbps | 70 Gbps |
| Gigabit RJ45 Ports | 24 | 24 | 48 | 48 |
| SFP+ Ports | N/A | N/A | 2 | 2 |
| SFP Ports | 2 | 2 | 2 | 2 |
| Max. Power Consumption | 250W | 500W | 500W | 750W |
Specifications for ES-24-250W Ubiquiti EdgeSwitch 24-Port PoE Switch 250W
| Mechanical | |
|---|---|
| Dimensions | 485 x 43.7 x 285.4 mm (19.1 x 1.7 x 11.2″) |
| Weight | 4.7 kg (10.4 lb) |
| Hardware | |
| Networking interface | (24) 10/100/1000 Mbps RJ45 Ethernet ports (2) 1 Gbps SFP ports |
| Management interface | (1) RJ45 serial port, Ethernet In/Out-Band |
| Total non-blocking throughput | 26 Gbps |
| Switching capacity | 52 Gbps |
| Forwarding rate | 38.69 Mpps |
| Power method | 100-240V AC, 50-60 Hz, universal input |
| Power supply | AC/DC, internal, 250W |
| Max. power consumption | Includes PoE output: 250W Excludes PoE output: 30W |
| LEDs | RJ45 ports: PoE, speed/link/activity SFP ports: speed/link/activity |
| Rackmount | Yes, 1U High |
| ESD/EMP protection | Air/contact: ±24 kV |
| Shock and vibration | ETSI300-019-1.4 Standard |
| Ambient operating temperature | -5 to 40° C (23 to 104° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| PoE Per Port | |
| PoE interface | PoE/PoE+ (Pins 1, 2+; 3, 6-) 24V DC passive PoE (Pins 4, 5+; 7, 😎 |
| Max. PoE+ wattage per port by PSE | 34.2W |
| Voltage range PoE+ mode | 50–57V |
| Max. passive PoE wattage per port | 17W |
| 24V passive PoE voltage range | 20-27V |
Buy ES-24-250W Ubiquiti EdgeSwitch 24-Port PoE Switch 250W from Almiria Techstore Kenya in nairobi
