Ubiquiti Dream Machine Pro Max (UDM-Pro-Max)

Ubiquiti Dream Machine Pro Max (UDM-Pro-Max)

The Ubiquiti Dream Machine Pro Max (UDM-Pro-Max) is a next-generation 10G UniFi Cloud Gateway that delivers exceptional performance, advanced security, and unmatched scalability for modern enterprise networks. It supports 200+ UniFi devices, 50+ cameras, and more than 2,000 simultaneous clients, making it ideal for large businesses, campuses, data centers, and high-demand IT environments in Kenya. Moreover, it unifies routing, security, SD-WAN, NVR storage, and UniFi application hosting into a powerful 1U rack-mount platform—available now from Almiria Limited Kenya.

Product Overview

This upgraded Dream Machine Pro Max offers faster processing, expanded memory, and advanced WAN flexibility to support large, distributed networks. Therefore, it serves as a complete infrastructure solution, integrating UniFi Network, Protect, Access, Talk, and Connect applications in one device. Its dual 3.5″ HDD bays enable redundant NVR storage for camera deployments, which is ideal for organizations needing reliable surveillance archiving.

In addition, the UDM-Pro-Max features 5 Gbps IDS/IPS security routing, multiple 10G interfaces, and license-free SD-WAN. As a result, businesses can centralize management, enhance network security, and maintain high throughput with ease. The 1.3″ touchscreen display further simplifies monitoring with real-time network and system insights.

Key Features

• High-performance enterprise routing – Achieve up to 5 Gbps IDS/IPS throughput for strong, real-time network protection.

• Large-scale device support – Manage 200+ UniFi devices, 2,000+ users, and up to 50 HD or 15 4K cameras.

• Multi-WAN capability – Supports up to 8 WAN ports, including (1) 10G SFP+ and (1) 2.5 GbE for high-speed failover and load balancing.

• Full UniFi application suite – Includes UniFi Network, Protect, Access, Talk, and Connect for centralized device and service management.

• Redundant NVR storage – Features dual 3.5″ HDD bays for camera storage plus built-in 128 GB SSD for fast application performance.

• Advanced security features – Offers Layer 7 firewall, DPI, content filtering, intrusion prevention, and zone-based firewalling.

• Next-generation VPN & SD-WAN – Supports WireGuard, OpenVPN, Teleport VPN, IPsec, and license-free SD-WAN with Site Magic.

• Dynamic, policy-based routing – Includes OSPF, BGP, VLAN segmentation, and advanced NAT options.

• High-availability networking – Provides VRRP-based Shadow Mode gateway failover and optional UniFi LTE Backup.

• Touchscreen monitoring – Equipped with a 1.3″ LCM touchscreen for device status, alerts, and quick access.

Technical Specifications

• Brand: Ubiquiti

• Model: Ubiquiti Dream Machine Pro Max (UDM-Pro-Max)

• Form factor: 1U rack-mount Cloud Gateway

• Dimensions: 442.4 × 43.7 × 285.6 mm (17.4 × 1.7 × 11.2″)

• Weight: 4.7 kg (10.4 lb)

• Processor: Quad-core ARM Cortex-A57, 2.0 GHz

• System memory: 8 GB

• On-board storage: 32 GB eMMC + 128 GB integrated SSD

• NVR storage: (2) 3.5″ HDD bays

• Networking interfaces:

  • (8) 1 GbE RJ45

  • (1) 2.5 GbE RJ45 WAN

  • (2) 10G SFP+ (LAN & WAN)

• WAN capabilities: Up to 8 WAN ports

• Firewall & security: Stateful firewall, Layer 7 firewall, IDS/IPS (55,000+ signatures), content filtering, DPI

• VPN support: WireGuard, OpenVPN, Teleport, IPsec, L2TP, identity-based VPN

• Dynamic routing: OSPF & BGP

• QoS & networking: Advanced QoS, mDNS, DHCP server, IPv6 support, NAT customization

• Power: Internal 100W PSU; AC input 100–240V, optional USP-RPS DC input

• Power consumption: Max 60W

• Enclosure material: CNC aluminum & SGCC steel

• Operating temperature: -10 to 40°C (14 to 104°F)

• Operating humidity: 5–95% noncondensing

• Certifications: CE, FCC, IC, Anatel, SRRC

• NDAA compliant: Yes

These specifications make the UDM-Pro-Max one of the most capable and scalable UniFi gateways available.

Why Choose This Cloud Gateway?

Growing organizations need reliable performance and deep network visibility. Therefore, the UDM-Pro-Max consolidates routing, security, SD-WAN, switching control, camera storage, and application hosting into one platform. Its high-speed 10G interfaces and 5 Gbps IPS throughput help maintain smooth operations even under heavy load.

In addition, centralized UniFi management reduces IT complexity and makes large deployments easy to monitor. As a result, businesses across Kenya—from enterprises to educational institutions—can scale confidently while maintaining strong security and application performance. Finally, Almiria Limited Kenya supplies genuine Ubiquiti hardware and expert support for seamless deployment.

Final Recap & Call-to-Action

The Ubiquiti Dream Machine Pro Max (UDM-Pro-Max) delivers unmatched performance, 200+ device management, 10G connectivity, advanced security, and redundant NVR storage in a single enterprise-ready unit. Moreover, its SD-WAN, dynamic routing, and full UniFi application suite make it ideal for modern large-scale networks. Add to Cart or contact Almiria Limited Kenya to upgrade your infrastructure with the most powerful UniFi gateway available.
