Ubiquiti UniFi U7 Pro Outdoor (U7-Pro-Outdoor) Access Point

U7-Pro-Outdoor Technical Specifications

Overview

•  Dimensions:
  Without mount: 170 x 208 x 66.5 mm (6.7 x 8.2 x 2.6″)
  With mount: 170 x 208 x 121.8 mm (6.7 x 8.2 x 4.8″)
•  Weight: 1.2 kg (2.6 lb)
•  WiFi Standard: WiFi 7
•  Spatial Streams: 6
•  Coverage Area: 465 m² (5,000 ft²)
•  Max. Client Count: 300+
•  Uplink: 2.5 GbE
•  Mounting Locations: Wall, pole
•  Mounting Plate:  Included mount
•  Weatherproofing: IPX6 – IP67 with cable-gland door kit (included)
•  Power Method:  PoE+

Performance

•  MIMO
  • 5 GHz:      4 x 4 (DL/UL MU-MIMO)
  • 2.4 GHz:   2 x 2 (DL/UL MU-MIMO)
•  Max. Data Rate
  • 5 GHz:     8.6 Gbps (BW240)
  • 2.4 GHz   688 Mbps (BW40)
•  Antenna gain
  • 5 GHz:     Directional internal: 11 dBi / External omni: 8 dBi
  • 2.4 GHz:  Directional internal: 8 dBi / External omni: 6 dBi
•  Max. TX Power
  • 5 GHz:     29 dBm
  • 2.4 GHz:  23 dBm
•  Max. BSSIDs:   8 per Radio
•  Supported Data Rates
  • 802.11be (WiFi 7): 7.3 Mbps to 8.6 Gbps (MCS0 – MCS13 NSS1/2/3/4, EHT 20/40/80/160/240)
  • 802.11ax (WiFi 6): 7.3 Mbps to 4.8 Gbps (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160)
  • 802.11ac (WiFi 5): 6.5 Mbps to 3.4 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160)
  • 802.11n: 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)

Features

•  Wireless Meshing:  Yes
•  Band Steering:  Yes
•  802.11v BSS Transition Management:  Yes
•  802.11r Fast Roaming:  Yes
•  802.11k Radio Resource Management (RRM):  Yes
•  Advanced Radio Management:  Yes
•  Passpoint (Hotspot 2.0) Yes
•  Captive Hotspot Portal
  • Custom Branding Landing Page:  Yes
  • Voucher Authentication:  Yes
  • Payment-Based Authentication:  Yes
  • External Portal Server Support:  Yes
  • Password Authentication:  Yes
  • Guest Network Isolation:  Yes
•  Private Pre-Shared Key (PPSK): Yes
•  WiFi Speed Limiting: Yes
•  Client Device Isolation:  Yes
•  WiFi Schedules:  Yes
•  RADIUS over TLS (RadSec):  Yes
•  Dynamic RADIUS-assigned VLAN:  Yes

Hardware

•  Max. Power Consumption:  21W
•  Supported Voltage Range:  42.5—57V DC
•  Networking Interface:  (1) 1/2.5 GbE RJ45 port
•  Weight Device: 1.2 kg (2.6 lb),  With mount: 1.33 kg (2.9 lb)
•  Wind Loading:  74.6 N at 200 km/h (16.8 lbf at 125 mph)
•  Pole Mount Diameter:  1–2.5″ (25–63.5 mm)
•  Management:  Ethernet
•  Enclosure Material:  UV-stabilized polycarbonate, aluminum alloy
•  Mount Material:  UV-stabilized polycarbonate
•  LEDs
  • System (1) Power: White/Blue,  (4) Mesh signal: Blue
•  Certifications:  CE
•  Ambient Operating Temperature:  -30 to 60° C (-22 to 140° F)
•  Ambient Operating Humidity:  5 to 95% noncondensing
