TP-Link ES206GP Omada 6-Port Gigabit Easy Managed PoE+ Switch

TP-Link ES206GP Omada 6-Port Gigabit Easy Managed PoE+ Switch

The TP-Link ES206GP Omada 6-Port Gigabit Easy Managed PoE+ Switch is a compact networking solution designed for small businesses, offices, retail stores, and surveillance deployments. It combines six Gigabit Ethernet ports, four IEEE 802.3af/at-compliant PoE+ ports, and cloud-based management in a durable metal enclosure. As a result, it simplifies network expansion while providing reliable connectivity and power for compatible network devices.

Product Overview

The TP-Link ES206GP features six 10/100/1000 Mbps RJ45 ports, including four PoE+ ports that transmit power and data over a single Ethernet cable. With a total PoE power budget of 65 W and up to 30 W available per PoE port, it supports compatible devices such as IP cameras, wireless access points, and VoIP phones without requiring separate power adapters.

Moreover, the switch supports centralized cloud management through the Omada web interface and the Omada app, making remote administration simple. It also includes practical Layer 2 management features such as VLAN, Quality of Service (QoS), IGMP Snooping, automatic loop prevention, Port Isolation, and PoE Auto Recovery to improve network efficiency and stability.

Key Features

• Provides six Gigabit RJ45 ports for fast and reliable wired network connectivity.
• Includes four IEEE 802.3af/at-compliant PoE+ ports, allowing compatible devices to receive both power and data through a single Ethernet cable.
• Supports a 65 W PoE power budget, with up to 30 W available on each PoE+ port.
• Offers plug-and-play deployment, enabling quick installation while supporting additional management features when needed.
• Supports centralized cloud management through the Omada web interface and Omada app for convenient remote administration.
• Delivers PoE transmission up to 250 metres, making it suitable for compatible surveillance deployments over longer cable distances.
• Includes QoS, VLAN, IGMP Snooping, Port Isolation, PoE Auto Recovery, and automatic loop prevention to improve network reliability and traffic management.
• Features a fanless cooling design, ensuring quiet operation in offices and other indoor environments.
• Uses a durable metal casing with desktop and wall-mount installation options for flexible deployment.

Technical Specifications

• Brand: TP-Link
• Series: Omada
• Model: ES206GP
• Product Type: Easy Managed Gigabit PoE+ Switch
• Ports: 6 × 10/100/1000 Mbps RJ45 Ports
• PoE Ports: 4 × IEEE 802.3af/at PoE+
• PoE Power Budget: 65 W
• Maximum PoE Output per Port: 30 W
• Management: Centralized Cloud Management via Web and Omada App
• Network Features:
  • VLAN
  • Quality of Service (QoS)
  • IGMP Snooping
  • Port Isolation
  • PoE Auto Recovery
  • Automatic Loop Prevention
• Extended PoE Distance: Up to 250 m
• Enclosure: Metal
• Cooling: Fanless
• Mounting Options: Desktop and Wall Mount

Common Applications

The ES206GP is suitable for offices, retail shops, schools, hospitality environments, warehouses, and surveillance installations. It provides a practical solution for connecting and powering IP cameras, wireless access points, VoIP phones, and other IEEE 802.3af/at-compatible devices while maintaining reliable Gigabit network performance and simplified management.

Why Choose This Product?

The TP-Link ES206GP offers a practical combination of Gigabit switching, PoE+, and cloud-based management in a compact form factor. Its intelligent management features help improve network performance, while the fanless design ensures silent operation. Furthermore, the durable metal housing and flexible mounting options make it well suited for long-term deployment in a variety of professional networking environments.

FAQs

1. How many PoE+ ports does the TP-Link ES206GP provide?

The switch includes four IEEE 802.3af/at-compliant PoE+ ports that deliver both electrical power and Gigabit network connectivity through a single Ethernet cable.

2. What is the PoE power budget?

The ES206GP provides a total PoE power budget of 65 W, with each PoE+ port capable of delivering up to 30 W to compatible powered devices.

3. Can the switch be managed remotely?

Yes. It supports centralized cloud management through the Omada web interface and the Omada app, allowing administrators to configure and monitor the switch remotely.

4. Is the switch suitable for surveillance deployments?

Yes. It supports PoE transmission up to 250 metres and includes features such as Port Isolation and PoE Auto Recovery that help improve network reliability for compatible surveillance systems.

5. Does the ES206GP operate silently?

Yes. The switch uses a fanless cooling design, allowing it to operate quietly in offices, meeting rooms, retail spaces, and other indoor environments.
