Ubiquiti UNVR-PRO UniFi Protect Network Video Recorder Pro

Ubiquiti UNVR-PRO UniFi Protect Network Video Recorder Pro

The Ubiquiti UNVR-Pro Network Video Recorder is a 2U rack-mounted appliance for professional video security systems. It combines seven storage bays, high-capacity camera management, data protection, and UniFi Protect software. Therefore, it suits businesses that need centralised recording and simple remote management. Its scalable design supports offices, schools, hotels, retail sites, warehouses, and other multi-camera environments.

Product Overview

The UNVR-Pro records and manages video from compatible UniFi cameras. It supports up to 70 Full HD cameras, 35 2K cameras, or 24 4K cameras. In addition, its seven front-accessible bays accept 2.5-inch or 3.5-inch hard disk drives and solid-state drives.

A 10 Gigabit SFP+ port provides a high-speed network connection for demanding systems. Meanwhile, the Gigabit Ethernet RJ45 port offers standard wired connectivity. Administrators can manage the recorder through UniFi Protect. As a result, they can view live feeds, review recordings, and manage supported devices through a clear interface.

Key Features

• Seven drive bays: Seven 2.5-inch or 3.5-inch bays provide flexible storage for growing video archives.
• Large camera capacity: Manages up to 70 Full HD, 35 2K, or 24 4K cameras for multi-camera sites.
• 10 Gigabit networking: The SFP+ interface supports high-bandwidth links between the recorder and network infrastructure.
• Gigabit Ethernet: One RJ45 port provides a convenient wired management and network connection.
• Data protection: Built-in storage protection helps safeguard recorded footage when the system uses a supported drive configuration.
• Power redundancy: The USP-RPS input allows connection to a supported redundant power system for improved service continuity.
• Touchscreen display: A 1.3-inch front display provides quick access to useful system information.
• 2U rack design: The steel enclosure fits suitable equipment racks for organised professional installation.
• Unified management: UniFi Protect gives administrators one platform for cameras, recordings, alerts, and system settings.

Technical Specifications

• Brand: Ubiquiti
• Model: UNVR-Pro
• Product type: Network video recorder
• Managed cameras: Up to 70 Full HD, 35 2K, or 24 4K cameras
• Managed access hubs: Up to 150
• Drive bays: Seven 2.5-inch or 3.5-inch HDD or SSD bays
• Drive power budget: 135W maximum
• Network interfaces: One 10G SFP+ port and one Gigabit Ethernet RJ45 port
• Processor: Quad-core ARM Cortex-A57 at 1.7 GHz
• Memory: 8GB
• Display: 1.3-inch touchscreen
• Management: Ethernet
• Applications: UniFi Protect, UniFi Access, and UniFi Connect
• Power supply: Internal 200W AC/DC supply
• Power input: 100–240V AC, 3A maximum, 50/60Hz
• Redundant power input: 11.5V DC, 13.91A through USP-RPS
• Maximum power consumption: 160W
• Dimensions: 442 × 325 × 87mm
• Rack form factor: 2U
• Weight: 9.2kg without brackets and 9.5kg with brackets
• Enclosure: SGCC steel
• Operating temperature: -5°C to 40°C
• Operating humidity: 5% to 95% non-condensing
• Compliance: NDAA compliant
• Certifications: CE, FCC, IC, and Anatel 06697-21-08356

Common Applications

The recorder suits offices, schools, hotels, hospitals, shops, warehouses, campuses, and managed residential sites. It also supports larger installations that require central video storage. Furthermore, its rack format makes it suitable for server rooms and network cabinets with available 2U space.

Why Choose This Product?

The Ubiquiti UNVR-Pro Network Video Recorder combines high camera capacity with seven flexible storage bays. Therefore, an organisation can expand its recording system as storage needs grow. Front-accessible bays also make drive installation and maintenance easier.

Additionally, the 10G SFP+ interface supports data-heavy camera deployments. The redundant power input can improve continuity when paired with the supported power system. Overall, the UNVR-Pro provides structured video management for professional UniFi Protect installations.

Frequently Asked Questions

How many cameras can the UNVR-Pro manage?

It can manage up to 70 Full HD cameras, 35 cameras at 2K resolution, or 24 cameras at 4K resolution. However, actual storage duration depends on drive capacity, resolution, frame rate, retention settings, and recorded activity.

How many storage drives does it support?

The recorder has seven drive bays. Each bay supports a compatible 2.5-inch or 3.5-inch hard disk drive or solid-state drive. Consequently, administrators can select storage based on the system’s required capacity and retention period.

Does the UNVR-Pro include storage drives?

The official technical specifications identify seven supported drive bays but do not list installed drives as standard contents. Therefore, confirm the supplied package and purchase suitable storage drives separately when required.

Can the recorder fit in a server rack?

Yes. The UNVR-Pro uses a 2U rack-mounted design. Its dimensions are 442 × 325 × 87mm. Before installation, confirm that the intended rack has enough space, suitable support, ventilation, and power connections.

Does it support 10 Gigabit Ethernet?

Yes. It provides one 10G SFP+ interface for high-speed network connectivity. It also includes one Gigabit Ethernet RJ45 port. However, the required SFP+ module, cable, and connected network equipment must support the chosen link type.

Does it support redundant power?

Yes. The recorder includes a USP-RPS DC input for connection to a supported redundant power system. This option can provide power failover alongside the internal AC power supply.

Which management software does it use?

The Ubiquiti UNVR-Pro Network Video Recorder supports UniFi Protect for camera and recording management. It also supports UniFi Access and UniFi Connect, allowing it to serve compatible physical security and connected display environments.
