The Generic HDMI Faceplate creates a clean wall connection for digital audio and video equipment. It uses a single female HDMI coupler, allowing installers to route compatible cables through a wall without leaving a loose cable exposed. Therefore, it suits home entertainment systems, conference rooms, classrooms and gaming spaces that require a tidy connection between a source device and a display.

Product Overview

This wall plate provides one HDMI connection point within a standard single-gang installation. An HDMI cable connects to the rear of the coupler, while another cable connects equipment to the front. As a result, users can connect or disconnect devices without accessing the cable inside the wall.

The product listing states support for HDMI 2.0 signals, bandwidth up to 18Gbps and resolutions up to 4K at 60Hz. It also lists Audio Return Channel and High-bandwidth Digital Content Protection 2.2 passthrough.

However, the faceplate cannot improve the signal supplied by the connected equipment. The final performance depends on the source, display, cable quality, total cable length and every connection in the signal path. Therefore, all components must support the required resolution, refresh rate and HDMI features.

Key Features

• Single HDMI connection: Provides one organised wall-mounted port for compatible audio and video equipment.
• Female HDMI coupler: Accepts standard male HDMI cable connectors on the front and rear sides.
• Listed HDMI 2.0 support: Works with compatible HDMI 2.0 equipment and earlier HDMI connections.
• Up to 4K at 60Hz: The supplied product listing states support for 4K Ultra High Definition video at 60Hz.
• Up to 18Gbps bandwidth: Supports the listed data capacity when the complete cable path meets the same requirement.
• HDCP 2.2 passthrough: Allows compatible protected content to pass between supported source and display equipment.
• ARC passthrough: Supports Audio Return Channel when every connected device and cable supports the feature.
• Single-gang mounting: Fits a standard single-gang wall box for a neat indoor installation.
• White ABS housing: Provides a simple finish that blends with many office and home interiors.

Technical Specifications

• Product type: Single-port HDMI wall faceplate
• Connector: Female HDMI coupler
• Port configuration: One HDMI port
• Listed HDMI support: HDMI 2.0 and earlier versions
• Listed maximum resolution: 4K Ultra HD at 60Hz
• Listed maximum bandwidth: 18Gbps
• Listed content protection: HDCP 2.2 passthrough
• Listed audio feature: Audio Return Channel passthrough
• Material: ABS plastic
• Colour: White
• Mounting: Standard single-gang wall box
• Faceplate dimensions: 84 × 84mm

Common Applications

The Generic HDMI Faceplate suits home entertainment installations where a media player, decoder or gaming console connects to a television. For example, an installer can place the wall port behind the television and route the main cable inside a suitable conduit.

In addition, businesses can use the plate in meeting rooms to create an accessible laptop connection for a projector or display. Schools can also install it in classrooms with fixed presentation screens or interactive displays.

Gaming rooms and media spaces can benefit from the same layout. The faceplate keeps the main cable route out of sight while providing an easy connection point for equipment that users may change or disconnect.

Installation Guidance

First, confirm that the wall box matches the 84 × 84mm faceplate and provides enough depth for the coupler and cable connector. HDMI plugs need suitable clearance behind the plate. Therefore, avoid sharp bends that may place pressure on the cable or coupler.

Next, route a compatible HDMI cable through an appropriate low-voltage pathway. Then, connect it to the rear of the faceplate. Secure the plate to the wall box and connect the source or display cable to the front port.

Finally, test the complete signal path at the required resolution and refresh rate. If 4K at 60Hz does not work, check the source settings, display input, cable ratings, total distance and additional connections.

Why Choose This Product?

The Generic HDMI Faceplate provides a practical way to create a fixed audio-video connection without exposed in-wall cables. Its female coupler also allows users to replace the short external cable without disturbing the main cable route.

Moreover, the single-gang design supports a neat wall installation. The listed HDMI 2.0, 4K at 60Hz, ARC and HDCP 2.2 capabilities suit compatible audiovisual setups. However, installers must match the entire cable path to the required signal format.

Frequently Asked Questions

Does the faceplate support 4K at 60Hz?

The product listing states support for 4K at 60Hz and bandwidth up to 18Gbps. However, the source device, display and every HDMI cable in the connection must also support that signal format.

Does it use an HDMI input or output?

The faceplate uses a passive female HDMI coupler rather than a fixed input or output. Therefore, signal direction depends on the connected equipment and the features used within the complete HDMI installation.

Does the faceplate require power?

No separate power connection appears in the supplied specifications. The coupler passes HDMI signals between connected cables. However, long cable runs may need a suitable active solution depending on distance and signal requirements.

Can it carry audio and video?

Yes. HDMI carries compatible digital video and audio through one connection. The listing also states support for Audio Return Channel passthrough when the connected equipment and cables support that feature.
