Hikvision DS-3E1318P-EI/M 16 Port Fast Ethernet Smart POE Switch

Hikvision DS-3E1318P-EI/M – 16-Port Fast Ethernet Smart PoE Switch with Gigabit Uplink and 130W Power Budget

Enhance your network efficiency with the Hikvision DS-3E1318P-EI/M 16 Port Fast Ethernet Smart POE Switch. This high-performance switch is designed for seamless power and data transmission, making it an excellent choice for security systems, IP cameras, and enterprise networking. With 16 PoE ports, robust surge protection, and advanced VLAN support, it delivers reliable and secure connections.

For more details and purchasing options, visit the Hikvision CCTV section.

Key Features

• 16 x 10/100 Mbps PoE Ports: Ensure stable power and data transmission.
• Gigabit Uplink: 1 Gigabit RJ45 port and 1 Gigabit combo for high-speed connections.
• PoE Power Supply: IEEE 802.3af/at standards with a power budget of 130W.
• Extended Transmission: Supports up to 300m for long-range applications.
• VLAN Support: Configurable VLAN ID from 1-4094, enhancing network security.
• Surge Protection: 6 kV protection to prevent electrical damage.
• PoE Watchdog: Auto-detects and restarts non-responsive cameras.
• Rack Mountable: Durable metal shell with mounting ears for easy installation.
• Energy Efficient: 150W max power consumption, 20W in idle mode.
• Remote Management: Control via Hik-Partner Pro and Hik-Central Pro.

Technical Specifications

General

• Material: Metal shell
• Net Weight: 1.8 kg (4.0 lb)
• Gross Weight: 3.0 kg (6.6 lb)
• Dimensions: 440.00 mm × 44.00 mm × 220.80 mm (17.32” × 1.73” × 8.69”)
• Operating Temperature: 0°C to 45°C (32°F to 113°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Humidity: 5% to 95% (no condensation)
• Power Supply: 100-240 VAC, 50/60 Hz, Max. 3A
• Installation Mode: Rack-mounted with mounting ears

Network Parameters

• Ports: 16 × 10/100 Mbps PoE ports, 1 × Gigabit RJ45, 1 × Gigabit combo
• Switching Capacity: 9.2 Gbps
• Packet Forwarding Rate: 6.84 Mpps
• Internal Cache: 4 Mbits
• MAC Address Table: 16K entries

PoE Power Supply

• PoE Standard: IEEE 802.3af, IEEE 802.3at
• Max Port Power: 30W
• PoE Budget: 130W

Software Functions

• Long Range: Up to 300m for ports 1-16
• VIP Port: Prioritization for ports 1-8
• Port Isolation: Enhances network security
• Link Aggregation: Supports static link aggregation
• Loop Prevention: STP and RSTP support
• VLAN Support: 802.1Q VLAN configuration
• Remote Management: Via Hik-Partner Pro

Approvals & Certifications

• EMC: CE-EMC, IC, RCM
• Safety: CB, CE-LVD
• Environmental Compliance: RoHS, WEEE, REACH

Why Choose Hikvision DS-3E1318P-EI/M?

This smart PoE switch is an ideal solution for security networks and enterprise infrastructures. Its advanced power management, long-range support, and secure VLAN capabilities make it an excellent choice for IT professionals looking for a reliable and cost-effective networking solution.

Order Today!

Upgrade your networking infrastructure with the Hikvision DS-3E1318P-EI/M POE Switch. Get yours today from Almiriatechstore.
