• Audible alarms
  Provides notification of changing utility power and UPS power conditions
• Predicitive failure notification
  Provides early-warning fault analysis ensuring proactive component replacement.
• Disconnected battery notification
  Warns when a battery is not available to provide backup power.
• User-replaceable batteries
  Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
• Automatic self-test
  Periodic battery self-test ensures early detection of a battery that needs to be replaced.

• Plug-and-Play external batteries
  Ensures clean, uninterrupted power to the loads when adding extra runtime to the UPS.
• Rack/Tower convertible
  Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
• Flash upgradeable firmware
  Install maintenance releases of firmware remotely using FTP.

• LED status indicators
  Quickly understand unit and power status with visual indicators.
• Serial connectivity
  Provides management of the UPS via a serial port.
• Network manageable
  Provides remote power management of the UPS over the network.
• InfraStruXure Manager Compatible
  Enables centralized management via the APC InfraStruXure Manager.
• SmartSlot
  Customize UPS capabilities with management cards.

• Frequency and voltage regulation
  Gives higher application availability by correcting poor frequency and voltage conditions without using the battery.
• Power conditioning
  Protects connected loads from surges, spikes, lightning, and other power disturbances.
• Input power factor correction
  Minimizes installation costs by enabling the use of smaller generators and cabling.
• Generator compatible
  Ensures clean, uninterrupted power to protected equipment when generator power is used.
• Cold-start capable
  Provides temporary battery power when the utility power is out.
• Resettable circuit breaker
  Easy recovery from overloads; no need to replace a fuse.
• Safety-agency approved
  Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

• Scalable runtime
  Allows additional run time to be quickly added as needed.
• Intelligent battery management
  Maximizes battery performance, life, and reliability through intelligent, precision charging.
• Hot-swappable batteries
  Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
• Automatic restart of loads after UPS shutdown
  Automatically starts up the connected equipment upon the return of utility power.
• Temperature-compensated battery charging
  Prolongs battery life by regulating the charge voltage according to battery temperature.
• Automatic internal bypass
  Supplies utility power to the connected loads in the event of a UPS power overload or fault.

• Low operating and maintenance costs with proven reliability and intelligent battery management.
  Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Automatic self tests insure battery reliability and warn customers in advance of battery replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down.
• Save time with easy and convenient remote/network accessibility.
  Network manageable via serial, USB or Ethernet. Includes Powerchute® Software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.
• Peace of mind that comes with full equipment compatibility and reliability of a leader
  Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry’s most rigorous standards.
• Avoids costly power problems by keeping your IT equipment and data protected and available.
  Network grade power conditioning protects from damaging surges and disruptive noise. The double conversion architecture provides tight voltage regulation, frequency regulation ,and zero transfer time to battery during power events

Output

• Output power capacity

  2.7 KWatts / 3.0 kVA

• Max Configurable Power (Watts)

  2.7 KWatts / 3.0 kVA

• Nominal Output Voltage

  230V

• Output Voltage Note

  Configurable for 220 : 230 or 240 nominal output voltage

• Output Voltage Distortion

  Less than 2%

• Output Frequency (sync to mains)

  50/60Hz +/- 3 Hz

• Other Output Voltages

  220, 240

• Load Crest Factor

  3 : 1

• Topology

  Double Conversion Online

• Waveform type

  Sine wave

• Output Connections
  (8) IEC 320 C13 (Battery Backup)
  (2) IEC Jumpers (Battery Backup)
  (2) IEC 320 C19 (Battery Backup)
• Bypass

  Internal Bypass (Automatic and Manual)

Input

• Nominal Input Voltage

  230V

• Input frequency

  40 – 70 Hz (auto sensing)

• Input Connections

  British BS1363A, IEC-320 C20, Schuko CEE 7/EU1-16P

• Cord Length

  2.44meters

• Input voltage range for main operations

  160 – 275V

• Input voltage adjustable range for mains operation

  100 – 275 (half load)V

• Number of Power Cords

  3

• Other Input Voltages

  220, 240

Batteries & Runtime

• Battery type

  Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

• Typical recharge time

  3hour(s)

• Nominal Battery Voltage

  96V

• Replacement Battery

  APCRBC152

• Expected Battery Life (years)

  3 – 5

• RBC Quantity

  1

• Extendable Run Time

  1

• Extended Run Options

  APC-Smart-UPS-SRT-3000VA-230V

• Runtime
  View Runtime Graph
  View Runtime Chart
• Efficiency
  View Efficiency Graph

Communications & Management

• Interface Port(s)

  RJ-45 Serial , Smart-Slot , USB

• Control panel

  Multi-function LCD status and control console

• Audible Alarm

  Audible and visible alarms prioritized by severity

• Emergency Power Off (EPO)

  Yes

• Available SmartSlot™ Interface Quantity

  1

Surge Protection and Filtering

• Surge energy rating

  340Joules

• Filtering

  —

Physical

• Maximum Height

  432mm , 43.2CM

• Maximum Width

  85mm , 8.5CM

• Maximum Depth

  635mm , 63.5CM

• Net Weight

  31.3KG

• Shipping weight

  36.74KG

• Shipping Height

  246mm , 24.6CM

• Shipping Width

  599mm , 59.9CM

• Shipping Depth

  871mm , 87.1CM

• Color

  Black

• Units per Pallet

  6.0

Environmental

• Operating Temperature

  0 – 40 °C

• Operating Relative Humidity

  0 – 95% non-condensing %

• Operating Elevation

  0-3000meters

• Storage Temperature

  -15 – 45 °C

• Storage Relative Humidity

  0 – 95% non-condensing %

• Storage Elevation

  0-15000meters

• Audible noise at 1 meter from surface of unit

  55.0dBA

• Online thermal dissipation

  703.0BTU/hr

• Protection Class

  IP 20

Conformance

• Approvals

  CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE

• Standard warranty

  3 years repair or replace (excluding battery) and 2 years for battery
